Kit #701 installation instructions
THIS SYSTEM SHOULD BE CHECKED DAILY
FOR PROPER OPERATION
1)
Install the alarm module in the cab of the
vehicle, in an unobstructed location in the dash,
where the driver can easily hear it. If preferable,
use the two wire ties to attach the module securely
in place.
2)
Connect the red lead FROM THE MODULE
to the door switch lead 108D with the enclosed
connector, as shown in diagrams F and H. If the
wire numbers do not match, select the wire that is
switched "ON" when the door is opened.
3)
Drill a 15/64 inch (5.59 mm) hole in the dash
in a conspicuous location with an unobstructed
view from the driver and install the flashing red
indicator LED and the warning label per diagram
"H".
4)
Connect the RED lead from the LED to the
ORANGE lead from the module and the BLACK
lead from the LED to the green wire from the
module; diagram "H."
SBS
Parking Brake Alert
For FREIGHTLINER trucks
Advertisement
Table of Contents
Related Manuals for SBS 701
Summary of Contents for SBS 701
- Page 1 Parking Brake Alert Kit #701 installation instructions For FREIGHTLINER trucks THIS SYSTEM SHOULD BE CHECKED DAILY FOR PROPER OPERATION Install the alarm module in the cab of the vehicle, in an unobstructed location in the dash, where the driver can easily hear it. If preferable, use the two wire ties to attach the module securely in place.
- Page 2 Remove the backing from the “Set Parking Brake” washer and install the washer around the LED. Connect black wire from the module to frame ground. Locate the parking brake air line as shown on the enclosed diagrams G. Insure you have the correct line.
- Page 3 12 inches green wire 12 inches orange wire 36 inches red wire 18 inches black wire 1 Slip-fit Tee SBS module with alarm attached 2 wire ties Installation instructions Manufactured and sold by: Safety Brake Set Inc. 3508 Cascade Hwy N.E.
