Summary of Contents for Polyaire Zonemaster
- Page 1 SINGLE ZONE CLIMATE ZONING SYSTEM Technical Manual Polyaire™ Pty Ltd 11-13 White Road GEPPS CROSS South Australia, 5094 Tel: (08) 8349 8466 Fax: (08) 8349 8446 www.polyaire.com.au...
-
Page 3: Table Of Contents
Appendix B - Single VAV Product Code Liability Please read the instructions before installing this Zonemaster System. Polyaire Pty Ltd does not accept any responsibility for loss or damage that may occur as a result of the installation of this System. -
Page 4: Features
• Max (or fully open) control. APPLICATION Zonemaster single VAV system is a fully featured and engineered system that is well suited to all ducted, reverse cycle, heating and evaporative air conditioning systems for light commercial, residential or apartment applications. It is especially designed for an area with dynamic heat loads, and where a constant or exact temperature is required. -
Page 5: Components
COMPONENTS 1) Touchpad User can input control commands from the touchpad to turn a zone on/off and set temperature. The LCD on the touchpad displays clock, room temperature and zone status. 2) Damper Motor (Yellow) Damper Motor drives the blade of the damper to modulate the air from ducting to the zone. -
Page 6: Connection Diagram
CONNECTION DIAGRAM The cabling of the Zonemaster single VAV system is straightforward. The touchpad connects the damper motor and power supply in serial via an adaptor, and the temperature sensor can be plugged into the socket on the back of the touchpad, as shown in Figure 1. - Page 7 Connect the pre-tested cable to the touchpad. When power is applied, the LCD screen on the touchpad should show clock time and the temperature where the touchpad is located. Otherwise, check the power supply and the cable. Turn off the power and disconnect the touchpad.
-
Page 8: Commissioning Instruction
COMMISSIONING INSTRUCTION The Zonemaster single VAV has two parameters, room temperature and minimum ventilation, that should be set in the commissioning stage. 1. Initiating and Exit Setting Process 1) Hold down both buttons for about 5 seconds until the LCD displays ‘Setting’... -
Page 9: Damper On/Off Test
4. Damper on/off Test 1) Switch on the air conditioner. 2) Press button to turn the zone on or off to check if the damper is correctly connected by feeling the air at the outlet. Refer to User’s manual for the operation. TROUBLE SHOOTING GUIDE Problem Suggested Action... -
Page 10: User Manual
USER MANUAL The single VAV touchpad has an LCD screen and six buttons, as shown in Figure 2. In normal operation mode, the LCD screen will display clock time and the temperature at the location of the touchpad. Figure 5. Layout of the single VAV Touchpad Zone On/Off Control 1) In ‘on’... -
Page 11: Programming Mode
Programming Mode Programmable zone temperature control is an important feature of the Zonemaster single VAV system. This system has a 5-1-1 program capability which means the system has an individual program for weekdays (Monday to Friday), Saturday and Sunday respectively. Each program has 4 programmable events per day: Wake, Day, Back and Sleep, which can be turned on or off individually. - Page 12 Program Wake Back Sleep Start time 6.30AM 8.00AM 5.30PM 10.00PM Monday Set cool 24°C 24°C 30°C Friday Set heat 21°C 21°C 17°C Start time 7.30AM 12.30PM 6.00PM 11.30PM Saturday Set cool 24°C 24°C 24°C 30°C Set heat 21°C 21°C 21°C 17°C Start time 7.30AM...
- Page 13 Saturday: 7:30AM Wake, the zone turns on with a setpoint of 24°C for cooling mode and 21°C for heating mode. 12:30PM Day, the zone’ s temperature setpoint is set to 24°C for cooling mode and 21°C for heating mode. 6:00PM Back, the zone’ s temperature setpoint is set to 24°C for cooling mode and 21°C for heating mode.
- Page 14 Adjust Program Time 1) Press button twice, the LCD shows the program status. 2) Factory default status of the program is disabled that means no program control. Pressing button once will enable the program. 3) In enable status, pressing button will select each of the program data to be adjusted.
- Page 15 11) Press button again, the LCD will show the start time of the Day event of the program for Monday to Friday. 12) Follow step 4) to 10) to set the start time and cooling/heating setpoint of Day event or disable the event.
- Page 16 Programming Information Sheet The following program tables are designed to assist the user in programming. Program Wake Back Sleep Start time Monday Set cool Friday Set heat Start time Saturday Set cool Set heat Start time Sunday Set cool Set heat Page 13...
-
Page 17: Appendix A - Specifications
APPENDIX A - TECHNICAL SPECIFICATIONS Electrical Requirements Power supply 24VAC ± 10% Line frequency 50 Hz Components Power Consumption Touchpad 0.5 VA Damper controller 2.5 VA Environmental Requirements Operating temperature 0°C to 60°C Altitude 0 to 2000 metres Operating relative humidity 10% to 80% Avoid static electricity hazards Avoid electromagnetic radiation sources... -
Page 18: Appendix B - Single Vav Product Code
APPENDIX B - SINGLE VAV PRODUCT CODE Code Items Description Single zone VAV touchpad (1) Rechargeable battery (1) Zonemaster Single 7153 Adaptor (1) Zone VAV Mounting bracket kit (1) Technical manual (1) 7186 Supply Air Sensor Supply air sensor with 7M lead...
