- Page 1 Hardware Manual PC-I 04/PCI Passiv PC/CAN Interface The expert for industrial and automotive communication...
- Page 2 Internet: www.ixxat.de Internet: www.ixxat.com e-Mail: info@ixxat.de e-Mail: sales@ixxat.com Support In case of unsolvable problems with this product or other IXXAT products please contact IXXAT in written form by: Fax: +49 (0)7 51 / 5 61 46-29 e-Mail: support@ixxat.de Copyright Duplication (copying, printing, microfilm or other forms) and the electronic distribution of this document is only allowed with explicit permission of IXXAT Automation GmbH.
-
Page 3: Table Of Contents
4.3 Interrupt handling ............13 Notes for programmers ............14 Appendix..................15 Appendix A ................15 Technical data ................15 Appendix B................16 Delivery settings ..............16 Appendix C................17 Sources of data sheets............. 17 Copyright IXXAT Automation GmbH PC-I 04/PCI-Manual, Version 1.2... -
Page 5: Introduction
This handbook is intended to familiarize you with your interface, also referred to in the following as PC-I 04/PCI. Please read this handbook before beginning with the installation. Among other things, the handbook describes the hardware architecture of the interface, knowledge of which is necessary for creating your own drivers. -
Page 6: Block Diagram
PLX PCI9050 INT# INT# AD[0..7] Controller 1 Controller 2 SJA1000 SJA1000 CAN Bus CAN Bus Interface Interface CAN High CAN High CAN Low CAN Low Fig. 1-1: Block diagram PC-I 04/PCI interface Copyright IXXAT Automation GmbH PC-I 04/PCI-Manual, Version 1.2... -
Page 7: Installation
(5) Close the PC; the hardware installation is now complete. Software installation A driver is required in order to operate the interface. For the installation of the CAN driver VCI, please read the VCI-installation hand- book. Copyright IXXAT Automation GmbH PC-I 04/PCI-Manual, Version 1.2... -
Page 8: Configuration
Configuration 3 Configuration Settings on the interface Figure 3-1 shows the position of the plugs, figure 3-2 the jumpers on the inter- face. Fig. 3-1: PC-I 04/PCI interface – components side Copyright IXXAT Automation GmbH PC-I 04/PCI-Manual, Version 1.2... -
Page 9: Supplying Voltage Via Can-Plug
Configuration Fig. 3-2: PC-I 04/PCI interface – solder side 3.1.1 Supplying voltage via CAN-plug With the solder jumpers JP3, JP4, JP5, JP32, JP33 and JP36, VCC (5 V) or GND can be connected to the CAN-plugs of the two CAN-circuits. For this, the jumpers given in the following table are to be connected. -
Page 10: Connection To Ground For Measuring Purposes
Configuration 3.1.2 Connection to ground for measuring purposes There is a connection on the PC-I 04/PCI for a ground pin. The abbreviation GND is marked on the board next to the drill hole. Design of the CAN-plugs Two isolated high-speed bus attachments according to ISO 11898-2 can be mounted on the interface. -
Page 11: Bus Terminator
JP6 and for the second bus connection with JP7. Bus termination is with a 120 Ohm resistor between CAN Low and CAN High. On delivery, the jumpers JP6 and JP7 are not bridged. Therefore no bus termina- tor resistor is active. Copyright IXXAT Automation GmbH PC-I 04/PCI-Manual, Version 1.2... -
Page 12: Architecture
Triggering an interrupt on the PC The CAN-controllers can trigger an interrupt on the PC. Both CAN-controllers share one interrupt (INTA# of the PCI-interface). The PCI-plug and play BIOS allocates an interrupt to the card (IRQ3..IRQ15). Copyright IXXAT Automation GmbH PC-I 04/PCI-Manual, Version 1.2... -
Page 13: Interrupt Handling
PC. The PCI-bus interface chip PLX PCI9050-1 does not appear here. It should be noted that the PCI-bus interrupt in the PCI-specification is defined as level-triggered. With the ISA-bus, the interrupt was transition-triggered. Copyright IXXAT Automation GmbH PC-I 04/PCI-Manual, Version 1.2... -
Page 14: Notes For Programmers
Notes for programmers 5 Notes for programmers For more details on programming the CAN-controller and for example programs, visit the support area of our homepage (www.ixxat.de) or contact us via e-mail (support@ixxat.de). Copyright IXXAT Automation GmbH PC-I 04/PCI-Manual, Version 1.2... -
Page 15: Appendix
DIN EN 55024 (VDE 0878 part 24) /05.1999 Notes on EMC The PC/CAN-interface PC-I 04/PCI may only be installed in a PC with a CE symbol and with an RF-shielded housing. All cables connected to the interface must have a braiding which lies flat on the plug housing. The plug housing must be RF- shielded and have low inductive contact with the PC-housing. -
Page 16: Delivery Settings
The settings of the interface on delivery are listed in the following. With special versions of the interface, individual settings may vary. Jumper Setting on delivery closed open open open open JP32 closed JP33 open JP36 open Copyright IXXAT Automation GmbH PC-I 04/PCI-Manual, Version 1.2... -
Page 17: Sources Of Data Sheets
Appendix Appendix C Sources of data sheets CAN-controller Philips SJA1000: http://www.philips-semiconductors.com CAN-transceiver Philips PCA82C251: http://www.philips-semiconductors.com PCI-bus interface chip PLX PCI9050-1: http://www.plxtech.com Copyright IXXAT Automation GmbH PC-I 04/PCI-Manual, Version 1.2...
