This handbook is intended to familiarize you with your interface, also referred to in the following as PC-I 04/PCI. Please read this handbook before beginning with the installation. Features The most important technical features are as follows: •...
PLX PCI9050 INT# INT# AD[0..7] Controller 1 Controller 2 SJA1000 SJA1000 CAN Bus CAN Bus Interface Interface CAN High CAN High CAN Low CAN Low Fig. 1-1: Block diagram PC-I 04/PCI interface Copyright IXXAT Automation GmbH PC-I 04/PCI manual, Version 2.4...
For the installation of the CAN driver VCI, please read the VCI installation hand- book. Hardware-Installation Before you plug the PC-I 04/PCI into the PCI slot, you should install the software driver (see section 2.1). For all work on the PC and interface, you must be statically discharged. Work must be carried out on an earthed, anti-static work mat.
Configuration 3 Configuration Settings on the interface Figure 3-1 shows the position of the plugs, figure 3-2 the jumpers on the inter- face. Fig. 3-1: PC-I 04/PCI interface – components side Copyright IXXAT Automation GmbH PC-I 04/PCI manual, Version 2.4...
PC. 3.1.2 Connection to ground for measuring purposes There is a connection on the PC-I 04/PCI for a ground pin. The abbreviation GND is marked on the board next to the drill hole.
Signal name CAN Low GND (JP33) CAN High VCC (JP36) With galvanically isolated bus connections, the signals GND and VCC are also galvanically isolated from the power supply of the PC. Copyright IXXAT Automation GmbH PC-I 04/PCI manual, Version 2.4...
120 Ohm resistor between CAN Low and CAN High. On delivery, the bus connections are not active. Alternatively bus termination can also be made externally with the IXXAT accessory “SubD9 connector with CAN bus terminator resistor“ (order number 1.04.0075.03000).
CAN-controller is reset by an interrupt acknowledge by the PC. The PCI-bus interface chip PLX PCI9050-1 does not appear here. It should be noted that the PCI-bus interrupt in the PCI-specification is defined as level-triggered. Copyright IXXAT Automation GmbH PC-I 04/PCI manual, Version 2.4...
ESD protection CAN-bus: 12kV (Human Body Model) Max. number CAN-bus nodes: Galv. isolation bus connection: 1000 V DC between CAN1, CAN2 and internal logic Signal delay due to galv. isolation: typically 50 ns Copyright IXXAT Automation GmbH PC-I 04/PCI manual, Version 2.4...
Appendix Declaration of conformity IXXAT Automation declares that the product: PC-I 04/PCI with the article numbers: 1.01.0057.10100 1.01.0057.10200 1.01.0057.11110 1.01.0057.11220 do comply with the EC directives 2004/108/EC. Applied harmonized standards in particular: EN 55022:2006 + A1:2007 EN 55024:1998 + A1:2001 + A2:2003 23.08.11, Dipl.-Ing.
