U-Line BUNN H-3562 Operating Manual

π
H-3562
BUNN 2 BURNER
®
COFFEE MAKER
WARNING!
• Fill water tank before turning on thermostat or
connecting appliance to power source.
• Use only on a properly protected circuit
capable of the rated load.
• Electrically ground the chassis.
• Follow national/local electrical codes.
• Do not use near combustibles.
• Failure to comply risks equipment damage,
fire or shock hazard
• Read the entire operating manual before
using this product
• This appliance is heated whenever connected
to a power source
CAUTION! The brewer must be disconnected
from the power source throughout the
initial setup, except when specified in the
instructions.
1. Insert an empty funnel into the funnel rails.
2. Place an empty dispenser under the funnel.
3. Open the flip lid on top of the brewer and pour in
three pitchers of tap water. Allow approximately two
minutes between pitchers for water to flow into the
tank. While the third pitcher of water is entering the
tank, the tank will fill to capacity and the excess will
flow from the sprayhead, out of the funnel, and into
the dispenser. (See Figure 1)
PAGE 1 OF 2
1-800-295-5510
uline.ca

SAFETY

INITIAL SETUP

WARNING! To reduce the risk of electric shock,
do not remove or open cover. No user-
serviceable parts inside. Authorized service
personnel only. Disconnect power before
servicing.

ELECTRICAL REQUIREMENTS

CAUTION! The brewer must be disconnected
from the power source until specified in Initial
Setup.
The brewer has an attached cordset and requires 2-wire
grounded service rated 120 volts AC, 15 amp, single
phase, 60 Hz.
Figure 1
Funnel
Dispenser
0317 IH-3562
