Do not attempt to repair this product yourself. If the product or its power supply experiences any malfunction or damage, stop using it immediately and contact Kogan.com to arrange a repair. • This appliance includes a safety switch which prevents operation unless the accessories are securely installed.
Page 4
OVERVIEW Motor base Knob Driver Processing bowl Blade adapter Bowl cover Pusher Emulsifying disc Kneading blade Chopper blade French fry blade Fine shredding blade Coarse shredding blade Fine slicing blade Coarse slicing blade Blade holder Blender Blender lid Centre measure cup Citrus Juicing Plate Citrus Juicing Head...
Page 5
ASSEMBLY Chopper Blade Position Driver on motor base. Position processing bowl on Driver and turn clockwise to install firmly. Place blade adaptor onto the Driver. Place chopper onto the blade adaptor. Turn the chopper to the right position. Place cover on bowl, turn clockwise until cover interlocks on a bowl. Place pusher into the feeding chute.
Page 6
Kneading Blade Place Driver on motor base. Place bowl on Driver and turn clockwise to seat firmly on motor base. Place blade adaptor onto the Driver. Place kneading blade onto the blade adaptor. Turn the kneading blade to the right position. Place cover on bowl, turn clockwise until cover interlocks on a bowl.
Page 7
Fine and Coarse Slicing Blade, Fine and Coarse Shredding Blade, French Fry Blade Position Driver on motor base. Place bowl on Driver and turn clockwise to seat firmly on motor base. Install desired blade onto the blade holder. Place blade holder onto the Driver. Place cover on bowl.
Page 8
Emulsifying Plate Assembly Position Driver on motor base. Place bowl on Driver and turn clockwise to seat firmly on motor base. Place blade adaptor onto the Driver. Place Emulsifying plate onto the blade adaptor. Turn the Emulsifying plate to the right position. Place cover on bowl, turn clockwise until cover locks on a bowl.
Page 9
Citrus Assembly Notice: Install the citrus juicer attachment as above picture.
Page 10
Blender Assembly Make sure the blade base is fixed tightly. Put food into the jar. Install measuring cup and cover properly. Put blender jar onto motor base vertically and then rotate the jar clockwise to fix it. Tips and Warning •...
CLEANING & CARE Wash all parts except motor base in warm, soapy water. The discs can be disassembled to wash with water, but be careful during disassembling. DO NOT IMMERSE MOTOR BASE IN WATER. SPECIFICATIONS Voltage 20-240V/50Hz Rated power 750W Blender jar capacity 1800ml Processing bowl capacity (Maximum)
Page 12
This is a Quick Start Guide, and we hope that this has given you the assistance needed for a simple set-up. For the most up-to-date guide for your product, as well as any additional assistance you may require, head online to help.kogan.com...
