H0004703NA www.caleffi.com Start-up Guide for the gateway MODBUS RTU / BACnet © Copyright 2018 Caleffi Code NA10520 INSTRUCTION SHEET CONTENTS Certification and technical specifications Introduction Setup fo r the gateway Power and RS485 connections Use web configurator to setup the gateway... -
Page 2: Certification And Technical Specifications
2. INTRODUCTION The gateway is an external, high performance Building Automation multi-protocol gateway that is preconfigured to auto-discover any of Caleffi’s products (hereafter called “device”) connected to the the gateway and automatically configures them for BACnet MS/TP, BACnet/IP. It is not necessary to download any configuration files to support the required applications. -
Page 3: Setup For The Gateway
Each gateway has a unique part number located on the side or the back of the unit. This number should be recorded, as it may be required for technical support. The numbers are as follows: Model Caleffi code FPC-N34-1618 NA10520... - Page 4 BMS Network settings: MAC address, device instance and Baud rate BACnet MS/TP: Setting the MAC Address for BMS Network - Only 1 MAC Address is set for gateway regardless of how many devices are connected to gateway. - Set the BACnet MS/TP MAC Address of the gateway to a value between 1 to 127 (Master MAC Address); this is so that the BMS front end can find gateway via BACnet Auto-Discovery.
-
Page 5: Power And Rs485 Connections
Auto-Discovery: After completion - Turn Off to save configuration NOTE: if Modbus TCP/IP was selected for the field/BMS protocol, skip this section. Auto-Discovery is not used for MODBUS TCP/IP. The S3 DIP Switch for enabling Auto-Discovery should have been set in the previous chapter before applying power to the gateway. NOTE: Do not enable Auto-Discovery when the unit is powered. -
Page 6: Use Web Configurator To Setup The Gateway
Wiring diagrams: from devices (MODBUS-RTU) to Gateway (Ethernet) Device - Gateway connections Gateway Pins Devices Legiomix_6000_Series B (16) A (18) Legiomix_2_0_6000_Series Conteca_Easy_750_Series B (17) A (18) See the diagrams below for the connection for the different devices (from MODBUS to BACnet network). GATEWAY Legiomix 2.0 6000 Series Ethernet cable... - Page 7 To set up the gateway by different Operating System (Windows) follow the instruction below: 1 - Go to the start button and digit the following code: ncpa.cpl - For Windows 10 - For Windows 8 3 - Select “Internet Protocol Version 4” and confirm. 2 - Select “Properties”...
- Page 8 To set up the gateway for MAC systems follow the instruction below: 1 - Open “System Preferences” 2 - Go to “Network” and choose the Ethernet system connected, fill the correct setting for the IP BACnet gateway address Connecting to gateway Web Configurator After setting a local PC on the same subnet as the gateway (previous chapter), open a web browser on the PC and enter the IP Address of the gateway;...
- Page 9 The Active profiles section lists the currently active device profiles, including previous Web Configurator additions. This list is empty for new installations, or after clearing all configurations. To add an active profile to support a device, click the Add button under the Active Profiles heading. This will present a drop-down box underneath.The Current profile column that lists all the available profiles.
-
Page 10: Bacnet Ms/Tp And Bacnet/Ip
6. BACNET MS/TP AND BACNET/IP: SETTING NODE_OFFSET TO ASSIGN SPECIFIC DEVICE INSTANCES After setting a local PC to the same subnet as the gateway, open a web browser on the PC and enter the IP Address of the gateway; the default address is 192.168.1.24. -
Page 11: Led Diagnistics For Communications Between Gateway And Devices
The parameters of the select device are shown in the screen below. 9. LED DIAGNOSTICS FOR COMMUNICATIONS BETWEEN GATEWAY AND DEVICES See the diagram below for gateway led locations. Description The SPL LED will light if the unit is not getting a response from one or more of the configured devices The RUN LED will start flashing 20 seconds after power indicating normal operation. - Page 12 Appendix 1. “A” BANK DIP SWITCH SETTINGS Address Address...
- Page 13 Address Address...
- Page 14 Address Address...
- Page 15 Appendix 2. COMPLIANCE WITH UL REGULATIONS For UL compliance, the following instructions must be met when operating gateway. The units shall be powered by listed LPS or Class 2 power supply suited to the expected operating temperature range. The interconnecting power connector and power cable shall: - Comply with local electrical code.
-
Page 16: Appendix
Appendix 6. LEGIOMIX_6000_SERIES MODBUS RTU MAPPINGS TO BACNET Point Name BACnet Object Type BACnet Object ID Description Product type 6001 ID Modbus 1...247 Tmix Deg_C (Mixing temp.) °C Trec Deg_C (Recirculation temp.) °C Tmix Deg_F (Mixing temp.) °F Trec Deg_F (Recirculation temp.) °F State 1 - Regulation... - Page 17 Presence of Recirculation Probe 1 = Presence of Rec probe Anticlog 1 = Anticlog Legal Hour bit 2:0 bit 3:1 = Disabled bit 2:1 bit 3:0 = EUR bit 2:0 bit 3:1 = USA bit 2:1 bit 3:1 = Custom International System of Unit 0 = °C , 1 = °F LED Display Enable...
- Page 18 Appendix 7. LEGIOMIX_2.0_6000_SERIES MODBUS RTU MAPPINGS TO BACNET Point Name BACnet Object Type BACnet Object ID Description Model 6002 ID Modbus 1...250 °C/10 - °F/10 °C/10 - °F/10 ID Number 1701...9952 Serial Number 0001...9999 Status 0 = Motor test 1 = Zero acquisition 2 = Full scale acquisition 3 = Water mixing status 4 = Thermal shock status...
- Page 19 Point Name BACnet Object Type BACnet Object ID Description Minute 0...59 Check Battery 1 = confirmed ; 0 = not confirmed Day-hour 1 = confirmed ; 0 = not confirmed Daylight Saving Time 1 = enabled ; 0 = not disabled Time Format 1 = 12H ;...
- Page 20 Appendix 8. CONTECA_EASY_750_SERIES MODBUS RTU MAPPINGS TO BACNET Point Name BACnet Object Type BACnet Object ID Description Product 7500 ID Modbus 1...250 Heating Energy Cooling Energy Pulse Input 1 (DHW) Pulse Input 2 (DCW) Pulse Input 3 / kWh Pulse Input 4 / kWh Instantaneous Power Flow Rate...
