4-Bike Hitch Mount Carrier
1393100G
Date of Purchase: ___________________
The user must read and understand these Instruction Sheets and the Warranty.
Installation is the end user's responsibility and beyond Cequent Consumer Products control. Therefore,
Cequent Consumer Products exclusively limits its Warranty to the repair or replacement of a defective
product. Damage to your vehicle, your cargo or any person or property is excluded.
• Your Bike Carrier must be inspected for signs of wear, corrosion and fatigue before each use.
• Make sure your Bike Carrier is secure before every trip. Check at each stop to ensure your Bike Carrier is
secure.
• Remove your Bike Carrier when not in use and before entering automatic car washes.
• ALWAYS obey all posted speed limits and be aware of traffic conditions. Adapt your speed to the
conditions of the road and the load being carried.
• Check local and state laws governing projection of objects beyond the perimeter of a vehicle.
• Do not use your Bike Carrier for purposes other than those for which it was designed. Do not exceed
your Bike Carrier's rated capacity. The capacity is 120 lbs. or 54 kg.
• Your Bike Carrier will not prevent property damage that may result from improper loading, securing, or
driving.
• Do not attempt to drill, weld, or modify your Bike Carrier or any of the system components.
• Bike tires should be at least 6 inches away from exhaust pipe.
• DO NOT use this carrier with recreational vehicles, trailers or in off road situations.
Review all Warnings, Instructions, and Warranty information carefully. Failure to follow these warnings and
instructions will void the Warranty.
Call Cequent Consumer Products Technical Services at (800) 234-6992 or go to ReeseBrands.com, if you
have any questions regarding the use or the limits of your Bike Carrier.
For assistance with this product or to order
replacement parts, please contact:
Cequent Consumer Products, Inc.
29000-2 Aurora Road
Solon, OH 44139
Questions? (800) 234-6992
ReeseBrands.com
Before Using Your Bike Carrier
These Instruction Sheets contain
IMPORTANT safety information. Please
read and keep for future reference.
Rev D 11/16/2018
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Reese Explore CEQUENT 1393100G
Summary of Contents for Reese Explore CEQUENT 1393100G
- Page 1 4-Bike Hitch Mount Carrier These Instruction Sheets contain 1393100G IMPORTANT safety information. Please read and keep for future reference. Date of Purchase: ___________________ Before Using Your Bike Carrier The user must read and understand these Instruction Sheets and the Warranty. Installation is the end user’s responsibility and beyond Cequent Consumer Products control.
-
