- Page 1 PCSS 05-20V ORIGINAL INSTRUCTIONS MINI CORDLESS PORTABLE CIRCULAR SAW...
-
Page 2: Table Of Contents
This symbol indicates dangers to the health of persons https://hub.trotec.com/?id=44514 due to hand injuries. Warning This signal word indicates a hazard with an average risk level which, if not avoided, can result in serious injury or death. mini cordless portable circular saw PCSS 05-20V... -
Page 3: Safety
• If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock. mini cordless portable circular saw PCSS 05-20V... - Page 4 • Never hold piece being cut in your hands or across injury and fire. your leg. Secure the workpiece to a stable platform. It is important to support the work properly to minimise body exposure, blade binding, or loss of control. mini cordless portable circular saw PCSS 05-20V...
- Page 5 If saw blade is binding, it may • Do not use abrasive wheels. walk up or kickback from the workpiece as the saw is restarted. mini cordless portable circular saw PCSS 05-20V...
- Page 6 Warning of electrical voltage whilst adhering to the technical data. Before any work on the device, remove the mains plug We recommend using the power tool with original Trotec from the mains socket and the battery from the device! accessories.
- Page 7 The device is not a toy and does not belong in the hands of children. Warning Risk of suffocation! Do not leave the packaging lying around. Children may use it as a dangerous toy. mini cordless portable circular saw PCSS 05-20V...
-
Page 8: Information About The Device
Diamond saw blade Allen wrench Adapter for dust extraction 3-stage battery level indication Release button Green battery LED (quick charger ready for operation) Chip ejector Spindle lock Base plate TCT saw blade Clamping screw mini cordless portable circular saw PCSS 05-20V... - Page 9 All parts of an operating cycle must be considered for this (e.g. times at which the power tool is switched off and times when it is switched on but runs without load). mini cordless portable circular saw PCSS 05-20V...
-
Page 10: Transport And Storage
Warning Risk of suffocation! Do not leave the packaging lying around. Children may use it as a dangerous toy. • Dispose of the packaging material according to the national regulations. mini cordless portable circular saw PCSS 05-20V... - Page 11 Allow the battery (10) to cool down to room temperature. 5. Take the battery (10) out of the quick charger (8) by pressing and holding the release button (17) and pulling the battery (10) off the quick charger (8). mini cordless portable circular saw PCSS 05-20V...
- Page 12 1. Release the locking lever (1). 2. Set the maximum cutting depth to 28.5 mm. 2. Set the desired cutting depth on the cutting depth 3. Press and hold the spindle lock (20). scale (25). 3. Lock the locking lever (1) again. mini cordless portable circular saw PCSS 05-20V...
- Page 13 13. Refit the clamping flange (26) on the saw blade clamp (27). 10. Please note that the base plate (21) must be swung back in order to insert the saw blade. 14. Fit the clamping screw (23) onto the clamping flange (26). mini cordless portable circular saw PCSS 05-20V...
- Page 14 16. Tighten the clamping screw (23) by means of the Allen wrench (14). 17. Let go of the spindle lock (20). 18. Check whether the saw blade is properly locked in place. 19. Put the battery (10) back in. 3. Retighten the wing screw (7). mini cordless portable circular saw PCSS 05-20V...
-
Page 15: Operation
Remove any oil before starting to saw to prevent oil residues from reaching the wood. • When sawing lightweight construction materials, observe the legal regulations and recommendations of the material manufacturers. mini cordless portable circular saw PCSS 05-20V... - Page 16 8. Wait a moment until the motor has reached full speed. 9. Place the saw blade onto the workpiece and start sawing. 10. Move the device along the cutting line with a slight forward motion. mini cordless portable circular saw PCSS 05-20V...
-
Page 17: Available Accessories
• Check the quick charger for damages. Should the quick specified in the instructions may cause a risk of injury. charger be damaged, stop using it. Contact the Trotec customer service. • Check the battery terminals for dirt. Remove any dirt. -
Page 18: Maintenance
• Non-coated saw blades can be protected against corrosion by applying a thin layer of acid-free oil. Remove any oil before starting to saw to prevent oil residues from reaching the wood. mini cordless portable circular saw PCSS 05-20V... -
Page 19: Disposal
Manufacturer and name of the authorised representative of the technical documentation: Trotec GmbH Grebbener Straße 7, D-52525 Heinsberg Phone: +49 2452 962-400 E-mail: info@trotec.de Place and date of issue: Heinsberg, 23.03.2020 Detlef von der Lieck, Managing Director mini cordless portable circular saw PCSS 05-20V... - Page 20 Trotec GmbH Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
