READ AND SAVE THESE INSTRUCTIONS
OWNER'S INSTRUCTION MANUAL
FOR MODELS:20‐7409
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN
OPERATION. IF UNSURE CONSULT A QUALIFIED ELECTRICIAN
Professional Installation Recommended
Note: Approximate time of assembly is 30 min to 1 hour.
These instructions are suitable for ETL/CETL Listed Ceiling fan.
Advertisement
Table of Contents
Related Manuals for Hardware House 20-7409
Summary of Contents for Hardware House 20-7409
- Page 1 READ AND SAVE THESE INSTRUCTIONS OWNER’S INSTRUCTION MANUAL FOR MODELS:20‐7409 CAUTION READ INSTRUCTIONS CAREFULLY FOR SAFE INSTALLATION AND FAN OPERATION. IF UNSURE CONSULT A QUALIFIED ELECTRICIAN Professional Installation Recommended Note: Approximate time of assembly is 30 min to 1 hour. These instructions are suitable for ETL/CETL Listed Ceiling fan.
-
Page 2: Table Of Contents
Table of Contents: Safety Tips ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐2 Unpacking your fan ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐3 Tools and Material Required‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4 Electrical Outlet box &Feature‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4 Preparing for installation ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐5 Mounting Bracket Installing‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐5 Hanging System Installation‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐6 Blade Assembly ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐7 Mounting ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐7 Wiring ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐8 Secure to Ceiling ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐8 Light Fixture Installation ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐9 Remote controller operation‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐10 Operation and Maintenance‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐11 Trouble Shooting‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐12... -
Page 3: Safety Tips
SAFETY TIPS To avoid possible electric shock, turn off the electricity at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. CAUTION: READ ALL INSTRUCTIONS AND SAFTY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS. -
Page 4: Unpacking Your Fan
UNPACKING YOUR FAN 1. Unpack your fan and check the contents. Do not discard the carton. If warranty replacement or repair is ever necessary the fan should be returned in original packaging. Remove all parts and hardware. Do not lay motor housing on its side: the decorative casting may shift. -
Page 5: Tools And Material Required
TOOLS AND MATERIALS REQUIRED Phillips screw driver Blade screw driver Adjustable pliers or wrench Step Ladder Wire cutter Electrical tape ELECTRICAL OUTLET BOX& FEATURE 1. If there is an existing outlet box, ensure it is clearly marked”suitable for fan support”. -
Page 6: Preparing For Installation
PREPARING FOR INSTALLATION Use metal outlet box suitable for fan support(must support 50lbs). Before Unpack and inspect fan carefully to be attaching fan to outlet box, ensure the certain all contents are included. outlet box is securely fastened by at least Turn off power at fuse box to avoid two points to structural ceiling member(a possible electrical shock. -
Page 7: Hanging System Installation
HANGING SYSTEM INSTALLATION Use the downrod supplied with fan, Place downrod assembly(1) into remove clamp pin(1) and cross pin(2) canopy(2)and yoke cover(3). Feed motor form downrod(3). wires through the downrod assembly(1). Insert down‐rod into down‐rod coupling ON FAN MOTOR HOUSING. Make sure to align hole in downrod with the hole in downrod coupling. -
Page 8: Blade Assembly
BLADE ASSEMBLY Rotate motor to make screw hole align to connection box U slot, then attach blade assembly Attached blade holders to blades to motor using motor screws provided. Tighten using the screws(1) and fabric screws securely, repeat this procedure for all washers(2). -
Page 9: Wiring
WIRING Make wiring connections from the house and the motor to the remote receiver as shown above. Connect using wiring nuts(provided). Once wiring step has been completed, slide the wired remote receiver in between the mounting bracket and the top of the downrod ball for downrod fans. -
Page 10: Light Fixture Installation
LIGHT FIXTURE INSTALLATION Lift the light pan to connection box’s remaining 3 screws which go through three key holes and rotate the light pan clockwise to align holes, then tighten REMOVE ONE SCREW FROM CONNECTION all 4 screws. BOX,REMAINS THREE SCREWS. Connect the terminals from the fan light to the terminals from the motor. -
Page 11: Remote Controller Operation
REMOTE CONTROL OPERATION 1.Codes: This remote control is preset WITH a pair of codes when being manufactured. Codes are set by pushing dip switches up or down. It is imperative that the code used for both transmitter and receiver is exactly the same, otherwise remote controller will not work. Please note the code switch will enable you to operate a second remote controller independently. -
Page 12: Operation And Maintenance
OPERATION AND MAINTENANCE Operation Turn on the power and check operation of fan. Speed settings for warm or cool weather depend on factors such as room size, ceiling height, number of fans and so The reversible switch controls direction, forward or reverse. Warm weather/ S position - (Forward) Fan turns in counter clockwise direction. -
Page 13: Trouble Shooting
TROUBLE SHOOTING GUIDE If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defect. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, please consult with your authorized electrician and do not attempt any electrical repairs yourself.
