Hamilton STA Operational Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
STA Validator Operational
Manual
Document #101-0011
1
1/09/07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STA and is the answer not in the manual?

Questions and answers

Related Manuals for Hamilton STA

Summary of Contents for Hamilton STA

  • Page 1 STA Validator Operational Manual Document #101-0011 1/09/07...

  • Page 2: Table Of Contents

    III. ELECTRICAL CONNECTIONS ..............7 IV. TESTING ....................... 8 V. MAINTENANCE ....................9 MONTHLY - Depending on use ......................9 YEARLY ............................... 9 STA Validator Calibration ........................9 VI. PARTS ........................11 APPENDIX A ............................. 13 Validator Dimensions ........................13 APPENDIX B ............................ 14 Opening the Bill Path .........................
  • Page 3 ABOUT THIS MANUAL This manual will enable the operator to complete basic maintenance, identify error codes, and perform basic troubleshooting. An electrical connection diagram and Validator package dimensions are provided to assist operators in cus- tomizing the Validator to individual needs. There are no user serviceable parts inside the Validator.

  • Page 4: Introduction

    I. INTRODUCTION The STA VALIDATOR is a state of the art, optical reading bill acceptor capable of validating one, five, ten or twenty dollar bills. The STA can also accept the patented Hamilton paper Tokenotes®. Tokenotes® are only interchangeable between the STA Validator and HV-X Validators.

  • Page 5: Switch Settings

    Accept $20 Reject $20 When programming Tokenotes® with the STA, all switches need to be set to the “ON” position. The switches should be turned “ON” from BOTTOM to TOP, starting with switch 8. When programming is complete, the switches should be turned “OFF” from TOP to BOTTOM, starting with switch 1. This will prevent accidental entry into any diagnostic modes.
  • Page 6 The STA should not be used with tube-style machines. Switch #5 selects whether the Validator will accept or reject $1 bills. If the switch is in the OFF position, the Validator will accept $1 bills. If the switch is ON, the Validator will reject $1 bills.

  • Page 7: Electrical Connections

    III. ELECTRICAL CONNECTIONS The electrical connections are made via a 9-pin connector located on the rear panel of the unit. The following diagram and chart have been included for custom installation. 9-PIN CONNECTOR EXTERNAL VIEW WIRE VIEW Pin # Color Name Blue Enable...

  • Page 8: Testing

    IV. TESTING After installation, a short test may be performed to verify correct installation. For testing, be sure Switch #1 is off. TEST DESIRED RESULT Turn on unit. Version is displayed for approximately 3 seconds. The display changes to 00 and then counts to 49 rapidly before stopping at the flashing decimal point indicating the unit is ready.

  • Page 9: Maintenance

    Clean rollers, heads, belts and sensors with cotton swabs and rubbing alcohol. Close the platen assembly. YEARLY The STA Validator should be serviced annually to maintain maximum performance. THIS WORK SHOULD ONLY BE DONE BY A TRAINED TECHNICIAN. STA Validator Calibration Take a clean piece of white copier paper and cut it to the size of a bill (test bill).
  • Page 10 PARTS LIST Part # Description Qty. 46-1037 ROLLER, PRESSURE 46-1038 LEVER, HEAD 46-1041 LEVER, HEAD ASSM. 46-1042 SPRING, HEAD 46-1043 ROLLER, HEAD 46-1044 SPRING, PRESSURE 46-1099 MOV HSV VAL 46-6502 CAPACITOR, 1 MFD 35 V 46-6530 CAPACITOR, 22 MFD 50 V 46-8501 12 PIN HEADER 46-8518...

  • Page 11: Parts

    VI. PARTS ERRORS ON POWER UP Error Problem/Solution Code Optical Sensor error./ Make sure Sensors are not blocked or dirty. Return for service. Optical Sensor error./ Make sure Sensors are not blocked or dirty. Return for service. Optical Sensor error./ Make sure Sensors are not blocked or dirty. Return for service. Optical Sensor error./ Make sure Sensors are not blocked or dirty.
  • Page 12 BILL ACCEPTANCE ERROR CODES Error Error Description Code All of the bill accept switches are turned off. Clears when switches are reset. New Style Money-Bill Magnetics Error. Tokenote-did not find end marker. Clears on next bill. New/Old Style Money-Visual rejection/total error too high. Tokenote-too many digits on Tokenote. Clears on next bill.

  • Page 13: Validator Dimensions

    APPENDIX A Validator Dimensions Document #101-0011 1/09/07...

  • Page 14: Opening The Bill Path

    APPENDIX B Opening the Bill Path Document #101-0011 1/09/07...
  • Page 15 Seller further warrants all repair or service work performed by a factory trained representative or Hamilton Manufacturing Corp. for a period of ninety (90) days from the date the repair or service work was performed. Purchaser’s remedies and the liabilities and obligations of Seller herein shall be limited to repair or replacement of equipment as Seller may choose, and Seller’s obligation to remedy such defects shall not...
  • Page 16 Seller expressly disclaims any warranty for any losses due to bill manipula- tion or theft or loss of cash under any circumstances. No person or entity other than a factory trained representative or Hamilton Manufacturing Corp. has performed or attempted to perform the subject repair or service.
  • Page 17 Document #101-0011 1/09/07...
  • Page 18 Hamilton Manufacturing Corporation 1026 Hamilton Drive Holland, OH 43528 Sales Phone: (888) 723-4858 Sales Fax: (419) 867-4850 Customer Service Phone: (800) 837-5561 Customer Service Fax: (419) 867-4857 Parts Phone: (866) 835-1721 Parts Fax: (419) 867-4867 Website: http://www.hamiltonmfg.com Email Addresses: service@hamiltonmfg.com sales@hamiltonmfg.com...
