Anywire ARW-RH System Product Manual

AnyWire Remote head for Address Writer
ARW-RH
ARW-04
The Product Guide describes individual products. Refer to the Guide as necessary.

[Notes on Safety]

Precautions that must be observed in order to use this system safely are indicated as shown below.
You must observe these precautions.
A WARNING indicates a potentially hazardous
situation which, if not handled correctly, could
result in death or serious injury.
WARNING
○ System Safety
This system is intended for general industrial applications. It does not have functions for supporting applications requiring higher
levels of safety such as safety-related devices or accident prevention systems. The product must not be used for these purposes.
WARNING
○ Always turn off the power before attempting to mount or replace.
○ System power supply
Use a stable, 24V DC power supply. Use of an unstable power supply may cause problems with the system.
○ Separately route high-voltage and power cables
CAUTION
Although the AnyWire System has a high noise margin, keep the transmission line and I/O cables away from high-voltage and
power cables.
○ Connectors and terminals
・ Pay careful attention to the length and installation of cable wiring to ensure that connectors and cables are neither overloaded nor disconnected.
・ Make sure to prevent any metal objects from getting inside the connectors or the terminal blocks.
・ Short-circuits caused by metal objects or mis-wiring are likely to damage the device.
○ Do not impose any external loads on the units. Doing so may cause a failure.
○ Do not disconnect or reconnect between the transmission line and slave units. A malfunction may occur.
○ Use the AnyWire System within the range of the speci cations and conditions shown below.

[Features]

- It is connected to AnyWire infrared non-contact address writer before use.
(Only RH connector built-in model)
- It makes writing in a narrow space or small-sized unit dif cult to be
handled by the body of address writer easier.
- Front communication and side communication are available.

[Type]

ARW-RH Adaptable model
AnyWire System Product Guide
ARW-03
ARW-04
ARW-03
A CAUTION indicates a potentially hazardous situation
which, if not handled correctly, may result in personal
injury or property damage.
CAUTION

[Warranty]

■ Warranty period
The warranty on the delivered Product shall continue to be effective for
one (1) year after the delivery thereof to a location as designated by the
original owner.
■ Scope of warranty
Should a defect occur in any part of the Product during the foregoing
warranty period when it is used normally in acordance with the speci ca-
tions described in this User's Manual, the Company shall replace or
repair the defect free of charge, except when it arises as a result of:
[1] Misuse or abuse of the Product by the owner;
[2] Fault caused by other than the delivered Product;
[3] The unauthorized modi cation or repair of the Product by any person
other than the Company's personnel;
[4] Any unusual force of nature, disaster or other cause beyond the Com-
pany's control.
The term "warranty," as used herein, refers to the warranty applicable to
the delivered product alone. The Company shall not be liable for conse-
quential or incidental damages resulting from any malfunction.
■ Repair at cost
After the expiration of the warranty period, the owner shall be responsi-
ble for all costs and expenses incurred for the troubleshooting and repair
of the Product. Even during the warranty term, the Company shall repair
any defects arising from causes other than within the scope of the
warranty as speci ed above, at the owner's cost.
-ARWRH 1/6-
(Product Manual)
