Rowlinson Garden Products Bali set Assembly Instructions

5. Operating the table extension

Fold the table extension into the middle of the table. Push the two table top sections together until they meet in the
middle. Table position should be secured using the latches on the underside of the table.
If in doubt of any aspect regarding the assembly, use or safety of your furniture set please contact us :
Help Line (Normal Office Hours) 01829 261 121
ROWLINSON GARDEN PRODUCTS LIMITED
Green Lane
Wardle Nr. Nantwich
Cheshire
CW5 6BN
We constantly improve the quality of our products, occasionally the
components may differ from the components shown and are only
correct at time of printing. We reserve the right to change the
specification of our products without prior notice.
2010 © Rowlinson Garden Products Ltd
Bali set table assembly
Assembly Instructions

Before assembly

•
We recommend that time is taken to
read the instructions before starting
assembly, then follow the easy step by
step guide. The instruction sheet is only
a guide to the assembly.
Certain items may not be shown
to scale.
•
Check all components prior to assembly
•
This product should be assembled
by no less than 2 people
x 2

Recommended tools for assembly

•
Allen Keys (supplied with kit)
•
Cross head screw driver
No. Components Qty.
1 Table top 1
2 Table Top Extension 1
3 Legs 2
4 Leg brace 1
5 Extension support 1
6 Leg Corner Supports 6
No. Fixing kit Qty.
7 90mm screws 4
8 60mm screws 8
9 40mm screws 16
10 Dowels 4
11 Allen key 1
English SS262
1
3
4
5
2
6
