Phoenix SS1160F Operating Instructions & Guarantee Registration

Memory Button
Door back or Top drawer back
FIRST OPENING ON FACTORY DEFAULT CODE
Factory code is 1 2 3 4 5 6
Touch the screen, to activate (1 bleep and screen illuminates).
1.
Enter the user code (1st time usage 123456).
2.
Touch OPEN, a melodic tone will sound and the display will
3.
show OPEnd.
Turn handle counter clockwise and open the door while the
4.
tone is sounding.
CAUTION
If an incorrect code is entered, Error will appear in the display
I.
panel and a short warning tone will sound.
If a wrong code is entered 5 times the lock will cease to oper-
II.
ate for 5 minutes. During which a warning tone will sound and
the display will indicate deLAY.
SETTING A NEW USER CODE
Set a new code with the door open and test the new code before
closing the door.
1. Touch the screen to activate
2. Touch ENTER
3. Type in the present code
4. Touch ENTER
5. Type in the new 4 – 16 digit code
6. Touch ENTER, a melodic tone will sound and the display will
show EntErd
For example:
If the present code is 1 2 3 4 5 6 and a new four digit code is
decided as 4 2 4 2 enter the following –
ENTER > 1 2 3 4 5 6 > ENTER > 4 2 4 2 > ENTER
EntErd will show in the display and a short tone will sound to
confirm the change to 4 2 4 2
SS1160F OPERATING INSTRUCTIONS
& GUARANTEE REGISTRATION
Upper part
Reset Button
Phoenix Safe Company where peace mind is guaranteed
Lower part
Battery Case
Hold the upper part and turn it counter-clockwise to
disassemble (1,5V AA Alkaline 4 pcs)
INTRODUCING A FINGERPRINT
Open the door using the user code. Keep the door open while
carrying out this process.
1. Press the M button on the back of door, the screen will be
activated
2. Press 3 on the screen
3. Press ENTER
4. Enter the user code and press ENTER
5. Scan in the fingerprint twice
consecutively, by placing the
finger on the sensor. The screen
will show EntErd a melody will
sound.
NOTE: Check the finger print had
been set correctly following -
How to open with a fingerprint.
• A total of 128 finger prints can be
introduced into the lock.
HOW TO OPEN WITH A FINGERPRINT
1. Touch the screen to activate
2. Scan the fingerprint on the sensor, the screen will show
OPEnd and a melody will sound.
3. Turn the handle counter clockwise and open the door while the
tone is sounding.
CAUTION
I. If an incorrect fingerprint is scanned, ErrOr will appear in the
display and a short warning tone will sound.
II. If a wrong fingerprint is scanned 5 times the lock will cease to
operate for 5 minutes. During which a warning tone will sound
and the display will indicate deLAY.
Upper
part
Lower
part
Securing
Hole
Put Finger-print twice
While red lamp flickering,
1
put user's finger on sensor.
After Bi- sound,
2
1
repeat the above
V1 JUL 2018
