DZNR label

DZNR label
You can use the label on the cover of the DZNR to identify the status indicator LED that is
assigned to each of the network devices. The label also includes quick reference information
for common diagnostic problems.
Each white box on the label corresponds to a status indicator LED mounted on the DZNR circuit
board. The LED indicates the status of the corresponding controller. Once the network
installation is finalized, shade the white boxes on the label to mark the location of each
controller. If the shading is done in pencil, future changes can be made by erasing the old
marks and filling in new ones.
The LEDs numbered from 0 through 99 correspond to controllers with that MAC address on
the network. Devices with MAC address above 99, including the CON-768 service tool which
assumes a default address of 127, are collectively monitored on the LED labeled as 100-127.
To determine controller status, compare the condition of the LEDs against the network layout
on the label. See Diagnostics and troubleshooting
for these LEDs.
1 6
0
26
SYSTEM 31
CONTROLLER
51 56
76 81
Class 2 5evice - All terminals Class 2 / SELV
Use 12 – 22AWG copper conductor only (65°C)
Ambient Rating: 32° to 132°C (0° to 55°C)
LNSTALL GUL5E
https://support.deltacontrols.com
LNPUT POWER:
24VAC 50/60Iz
SEG 1 SYSTEM CONTROLLER
CLASS 2, 7VA
MS/TP
2 WLRE
GN5 PWR
1 2
Page 18 of 28
11 16
36 41
61 66
86 91
SEG 2 ZONE CONTROLLERS
INPUT TYPE
MS/TP
ERR SELECTORS
2 WLRE
MS/TP
RJ-45 1 2
<-OR-> <-OR->
for a description of the illumination patterns
21 25
46 50
71 75
96 99
100-127
5ZNR-768
BACnet MS/TP REPEATER
Made in Canada
SEG 3 ZONE CONTROLLERS
MS/TP
ERR ERR
2 WLRE
MS/TP
RJ-45 1 2
<-OR->
DZNR-768 Revision 1.2 Installation Guide
5LAGNOSTLCS – UPPER STATUS LE5s
LE5 ON – CONTROLLER ON LLNE
LE5 CLASILNG CAST – 5UPLLCATE A55RESS
LE5 CLASILNG SLOW – CONTROLLER STOPPE5 COMMUNLCATLON
5LAGNOSTLCS – ERROR LE5s
GREEN = IEALTIY NETWORY
YELLOW = NETWORY MARGLNAL – CIECY LNSTALL GUL5E COR TLPS
RE5 = MAJOR NETWORY PROBLEM – SEGMENT LOCYE5 OUT
SEG 4 ZONE CONTROLLERS
MS/TP
ERR
2 WLRE
MS/TP
MS/TP
RJ-45 1 2
<-OR->
Document Edition 1.5
