Example network layout diagram

This diagram shows both a MS/TP 2- WIRE segment and a MS/TP RJ-45 segment.
Terminator
TRM-768
DAC
CAT5 branch using
ADP45-MSTP-Y
adapter
Add one two-wire RS-485 device
using ADP45-MSTP-TB-Y adapter
Short two-wire RS-485 wire
included with adapter
DZNR-768 Revision 1.2 Installation Guide
Document Edition 1.5
DAC DAC
DAC
NET2
DSC
Twisted Pair Segment
To DZNR port 1
Twisted Pair Segment
CAT5 Segment
ADP45-MSTP-EOL
End of Line
Loopback
Terminator
TRM-768
1
DZNR
ADP45-MSTP-EOL
End of Line
Loopback
