Lúbadh
Dual Looper
User Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the Dual Looper and is the answer not in the manual?

Questions and answers

Related Manuals for Instruo Dual Looper

Summary of Contents for Instruo Dual Looper

  • Page 1 Lúbadh Dual Looper User Manual...
  • Page 2 Contents Description / Features Latching & Momentary Recording Input Monitoring Modes Installation / Specifications Overview Looping & One Shot Record Modes Deck Specific Parameters Looping & One Shot Playback Modes Shared Parameters Time Modes Save & Load Capacitive Tape Reel Patch Examples CV Expansion Parameters - Basic Recording...
  • Page 3 Description Consisting of two identical channels Lúbadh allows you to instantly record, playback, overdub, trim down, scan through and pitch up or down any audio signal. Inspired by the aesthetics and mechanics of early tape techniques each channel features an analogue input circuit which adds slight compression, filtering and saturation.
  • Page 4 Installation 1. Confirm that the Eurorack synthesizer system is powered off. 2. Locate 20 HP of space in your Eurorack synthesizer case for the module. 3. Locate an additional 2 HP of space in your Eurorack synthesizer case for the optional CV expansion module. 4.
  • Page 5 Lúbadh lu:bɑ: | verb (willow weaving) loop, link, coil, twist, bend; meander of a river, to be fond of, wrapped up in Pre/Post Output Level Switch Rear PCB TIME TIME Capacitive Tape Reel Switch Input 13. Speed Indicator 25. Auxiliary Output 2.
  • Page 6 CV Expansion Module TIME TIME 1. Length CV Input (Left Deck) 2. Start CV Input (Left Deck) 3. Time CV Input (Left Deck) 4. Erase Trigger Input (Left Deck) 5. Length CV Input (Right Deck) 6. Start CV Input (Right Deck) 7.
  • Page 7 Deck Specific Parameters These parameters are specific to each deck, but function identically regardless of deck. Input: AC coupled audio input. Input Level: Input Level knob sets the level of the signal present at the Input. • If the Input Level knob is at its centre position, the signal present at the Input...
  • Page 8 • Record Button is also used to enter alternate modes (See the Input Monitoring Modes, Looping & One-Shot Record Modes, Save & Load, and Time Modes sections for more information). Record Gate Input: Recording, overdubbing, or playback (based on the currently selected mode) will be activated when a trigger or gate signal Record Gate Input.
  • Page 9 Speed CV Input: Speed CV Input is a bipolar control voltage input for Speed. • Control voltage is summed with the knob position. • Input range: -/+5V. Speed Indicator: Speed Indicator will illuminate white when the Speed parameter is set to a value that corresponds to the 0.5x playback rate, reversed 0.5x playback rate, original playback rate, reversed original playback rate, 2x playback rate, reversed 2x playback rate, 4x playback rate, reversed 4x playback rate or stalled playback.
  • Page 10 Retrigger/Shift Button: The loop will reset to the start position set by the Start parameter when the Retrigger/Shift Button is pressed. • Link Toggle If deck 2 is out of phase with deck 1 and the is enabled, Retrigger/Shift Button pressing the of deck 2 will spin the tape in either direction to resynchronize with deck 1.
  • Page 11 • When the knob is fully anticlockwise, the Clock Output will generate one trigger at the end of each loop. When the knob is fully clockwise, the Clock Output will generate 64 triggers per loop. Visual indication is shown via the Position Indicator upon selection of the multiplication factor.
  • Page 12 Shared Parameters Link Toggle: Link Toggle forces the right deck to mirror the LINK left deck’s controls. Left Deck Right Deck LINK Auxiliary Input: Auxiliary Input is an AC coupled audio input that normals to the Input of both decks. Auxiliary Input Crossfade: Auxiliary Input Crossfade determines...
  • Page 13 Auxiliary Input Crossfade CV Input: Auxiliary Input Crossfade CV Input Auxiliary is a bipolar control voltage input for the Input Crossfade. • Control voltage is summed with the fader position. • Input range: -/+5V. Auxiliary Output: Auxiliary Output is an AC coupled audio output that is normalled from the Output of both decks.
  • Page 14 Capacitive Tape Reel Capacitive Tape Reel: The play head graphic on the front panel is a capacitive touch plate that can be used for warble effects, stalling the loop, and delay time manipulation when the corresponding deck is empty and Delay Mode is enabled.
  • Page 15 CV Expansion Parameters Length CV Input: Length CV Input is a bipolar control voltage input for the Length parameter. • Control voltage is summed with the knob position. • Input range: -/+5V. Start CV Input: Start CV Input is a bipolar control voltage input for Start parameter.
  • Page 16 Normalisation Path A feedback path is created between the inputs and outputs on Lúbadh. Output of deck 1 is normalled to the Input of deck 2, which then passes to the Output of deck 2. The Output of deck 2 is normalled back to the Input of deck 1.
  • Page 17 Record, Overdub & Erase The Lúbadh currently records 9 minutes of audio per deck. It is important to note that the record head and the play head are decoupled. For instance, ½ speed playback can be set while full speed recording is taking place. To record to a deck, connect an audio signal to the Input of deck 1 and monitor from the Output of deck 1.
  • Page 18 Latching & Momentary Recording The Record Gate Input can be configured to Latching or Momentary. When set to Latching, the record state will change with every trigger or gate signal present at the Record Gate Input. When set to Momentary, the recording will be enabled for as long as a gate signal is held high.
  • Page 19 Input Monitoring Modes There are three Input Monitoring Modes. To toggle through the three Input Monitoring Modes, press and hold the Retrigger/Shift Buttons (1& 2) for deck 1 and deck 2, then press the corresponding deck’s Record Button (3). For example, deck 1’s Record Button is included in the button combination to toggle through Input Monitoring Modes for deck 1.
  • Page 20 Input Monitoring Enabled Mode This mode is indicated by a white illuminated Record Button (1). When this mode is active, input monitoring is always enabled. Audio signals present at the corresponding TIME TIME input will always pass to the output, summing with any recorded loops.
  • Page 21 Looping & One-shot Record Modes To toggle between Looping Record Mode and One-Shot Record Mode, Press and hold the Retrigger/Shift Button of the desired deck, then press the Record Button of the opposite deck. For example, to toggle between Looping Record Mode and One-Shot Record Mode on deck 1, press and hold the Retrigger/Shift Button (1) of deck 1, then press the Record Button (2) of deck 2.
  • Page 22 • Looping Record Mode is the default mode. • In One-Shot Record Mode, a loop must be recorded to determine the size of the loop. Any further recording will start from the current playback position and will record for the duration of time set by the first loop along with the Start and Length parameters.
  • Page 23 Looping & One-shot Playback Modes To toggle between Looping Playback Mode and One-Shot Playback Mode, Press and hold the Retrigger/Shift Button of the desired deck, then press the Erase Button of the opposite deck. For example, to toggle between Looping Playback Mode and One- Shot Playback Mode on deck 1, press and hold the Retrigger/Shift Button (1) of deck 1, then press the Erase Button (2) of deck 2.
  • Page 24 • Looping Playback Mode is the default mode. • In One-Shot Playback Mode, a loop must be recorded to determine the size of the loop. Pressing the Retrigger/Shift Button or sending a gate or trigger signal to the Retrigger Input will start playback of a full loop determined by the Start and Length parameters.
  • Page 25 Time Modes There are three separate functions for the Time knob Time Modes. To toggle called Time Modes through the three for a desired deck, press Retrigger/Shift and hold the Button (1), then press the corresponding deck’s Record Button (2). TIME TIME TIME...
  • Page 26 Tape Decay Mode In this mode, the Time knob sets how long Tape Decay Mode Delay 500ms recordings take to degrade when being (Multi Tap) (Mono Tap) recorded over. This is similar to analogue tape ageing. Shortest Infinite Complex Decay Time Decay Time Diffusion 3 Seconds...
  • Page 27 Save & Load Save: To save a recording to internal memory, press and hold the Retrigger/Shift Button and the Erase Button and then press the Record Button of the corresponding deck. For example, to save a recording from deck 1, press and hold the Retrigger/Shift Button (1) and the Erase Button (2)
  • Page 28 Load: To load a saved recording from internal memory to a desired deck, press and hold the Retrigger/Shift Button and then press the Erase Button of the corresponding deck. For example, to load a saved recording to deck 1, press and hold the Retrigger/Shift Button (1) and then press the Erase Button (2)
  • Page 29 Patch Examples Basic Recording: Summary: Audio is recorded, looped, and then monitored. Audio Signal Monitor Output Audio Path: • Connect any audio signal to the Input. • Set the Input Level to its centre position and set the Output Level fully clockwise.
  • Page 30 • Recording will be activated until the maximum duration has been met, if the Record Button is pressed while recording is activated, or if a gate or trigger signal is present at the Record Gate Input. • The loop will play once recording has stopped. Control Path: •...
  • Page 31 Equal Division Retrigger: Summary: Audio is recorded, looped, and then monitored. The clock generated by the loop will reset the loop to its position determined by Start parameter. This creates equal divisions of the loop without Length having to use the parameter.
  • Page 32 Deck Bouncing: Summary: Audio is recorded, looped, and edited on deck 1 and then bounced to deck 2. Monitor Output Audio Path: • Repeat the Audio Path section of the Basic Recording patch. • Set Speed, Start, and Length parameters to desired positions. •...
  • Page 33 Control Path: • Time Set the knob of deck 1 fully anticlockwise to generate one trigger signal per loop. • Clock Output Record Gate Input Connect the of deck 1 to the deck 2. Recording on deck 2 will start at the beginning of the loop on deck 1 and end at the beginning of the next loop on deck 1.
  • Page 34 Auxiliary Feedback Delay: Summary: Delay effect that includes only the wet signal. Control Voltage Monitor Output Audio Signal Audio Path: • Set deck 1 to Delay Mode. • Connect an audio signal to the Auxiliary Input. • Set the Output Level of deck 1 fully clockwise.
  • Page 35 Control Path: • Apply control voltage to the Time Input of deck 1 and Auxiliary Output Crossfade CV Input for delay time and feedback modulation.
  • Page 36 Dry/Wet Feedback Delay: Summary: Delay signal with control over delay time, feedback amount, and dry/wet mix. Control Voltage Audio Signal Monitor Output Audio Path: • Set deck 1 to Delay Mode. • Connect an audio signal to the Input of deck 2. •...
  • Page 37 • Set the Time parameter of deck 1 to a desired position. • Set the Auxiliary Output Crossfade to a desired position. This fader acts as a dry/wet mix control for the dry signal (deck 2) and the wet signal (deck 1). Control Path: •...
  • Page 38 Pitch Shifting Delay: Summary: Pitch shifting delay effect with control over feedback amount, and dry/wet mix. Monitor Output Audio Path: • Record a sample onto deck 1 • Bounce a fragment of the loop from deck 1 over to deck 2, the length of which determines the maximum delay length •...
  • Page 39 • Set the Output Level of deck 1 fully clockwise. • Set the Output Level of deck 2 fully clockwise. • Set the Input Level of deck 2 to fully clockwise. • Speed knob of deck 1 to Orginal Playback Speed. •...
