- Page 1 E.A.WL.CUS AirKey Montageanleitung | Assembly manual | Montagehandleiding Instructions de montage | Istruzioni di montaggio | Montážní návody Montážne návody | Instrukcje montażu | Installationsanvisningar...
- Page 2 Option E.A.WL.CUS IP54 E.ZU.WL.NT < E.A.WL._ _ E.TE.ZU.CU6 2,5/0,5 mm Option Technische Änderungen vorbehalten | Technical changes reserved...
- Page 3 CAT 5 max. 20 m up to 100 m – Rloop max. <2Ω Option...
- Page 4 AirKey control unit AirKey wallreader interface E.A.WL.CUS Wallreader 1 Wallreader 2 Power Supply 12V-24V/DC 1 2 3 4 Relais 1 Input 1 1 2 3 DOORBUS terminated (Default) DOORBUS open www.evva.com...
- Page 5 Ø6 mm 127,5 mm Option...
- Page 6 ≤ 3 sec/10 mm...
- Page 7 1 2 3 4 12V-24V/DC AirKey control unit AirKey control unit AirKey wallreader interface E.A.WL.CUS Wallreader 1 Wallreader 2 Power Supply 12V-24V/DC 1 2 3 4 Relais 1 Input 1 1 2 3 DOORBUS terminated (Default) DOORBUS open www.evva.com...
- Page 8 CAT 5 0,2 Nm AirKey control unit AirKey wallreader interface E.A.WL.CUS Wallreader 1 Wallreader 2 Power Supply 12V-24V/DC 1 2 3 4 Relais 1 Input 1 1 2 3 DOORBUS terminated (Default) DOORBUS open www.evva.com Option 0,5 Nm E.ZU.WL.NT 12V-24V/DC...
- Page 9 Option ≥ 3m ≥ 3m 0,2 Nm ~120°-220°C...
- Page 11 01 CONTROL UNIT WITH DC LOW CURRENT ELECTRIC STRIKE...
- Page 12 02 CONTROL UNIT WITH DC HIGH CURRENT ELECTRIC STRIKE...
- Page 13 03 CONTROL UNIT WITH AC ELECTRIC STRIKE...
- Page 14 04 CONTROL UNIT WITH EXTERNAL DOOR CONTROL UNIT...
- Page 16 EVVA Sicherheitstechnologie GmbH | Wienerbergstraße 59–65 | A-1120 Wien...
