Befaco JOYSTICK V1 Assembly Manual

JOYSTICK V1 - ASSEMBLY GUIDE – Rev. Feb 18
THANKS FOR CHOOSING ONE OF OUR KITS!
This manual has been written taking into account the common issues that we often find people
experience in our workshops. The order in which the components are placed on the board is
meant to make assembly as easy as possible.
Some steps are not obvious, so even if you're an experienced DIYer please read the steps
thoroughly before starting.
If this is your first project, please read this article before you start assembling the kit:
www.befaco.org/howto/
GOOD LUCK!

MAIN PCB

OPEN MAIN BOARD BAG A

RESISTORS

Qt Valu Code
y e
15 10k Brown, black, black, red, brown
8 100k Brown, black, black, orange, brown
4 1M Brown, black, black, yellow, brown
2 1k Brown, black, black, brown, brown
2 2.2k Red, red, black, brown, brown
2 3k Orange, black, black, brown, brown
2 4.3k Yellow, orange, black, brown, brown R28, R33
2 6.2k Blue, red, black, brown, brown
2 8.2k Gray, red, black, brown, brown
2 22k Red, red, black, red, brown
2 39k Orange, white, black, red, brown
2 82k Gray, red, black, red, brown
2 470k Yellow, violet, black, orange, brown
1 4.7k Yellow, violet, black, brown, brown

DIODES

Solder the diodes observing their polarity. The black or white line on the diode must
match with the white line on the diode symbol on the PCB silkscreen.
Qty Value
2 1N4148 (Orange)
2 1N5817 (Black ones)
Name on PCB
R5, R6, R20, R21, R22, R23, R25, R26, R30,
R31, R32 - place and solder same time as
R36 (2.2k), R35, R39, R40, R42
R13, R14, R15, R16, R29, R37, R43, R48
R3, R4, R41, R47
R7, R8
(R36 - should already be soldered), R38
R9, R24
R1, R2
R27 – be very careful not to fill the
adjacent hole, R34
R10, R17
R11, R19
R12, R18
R45, R46
R44
Name on PCB
D1, D2
D3, D4
