- Page 1 O P E R A T I O N M A N U A L NTG80 NOMAD TRANS-FLO™ AIR-OPERATED • DOUBLE DIAPHRAGM • PUMPS ALUMINUM Models DUCTILE IRON Models 316 STAINLESS STEEL Models A JDA Global Company...
- Page 2 NTG80 NOMAD TRANS-FLO™ CAUTION – SAFETY POINTS TEMPERATURE LIMITS: Neoprene -17.8°C to 93.3°C 0°F to 200°F Buna-N -12.2°C to 82.2°C 10°F to 180°F EPDM -51.1°C to 137.8°C -60°F to 280°F Viton -40°C to 176.7°C -40°F to 350°F Santoprene -40°C to 107.2°C -40°F to 225°F Polyurethane 12.2°C to 65.6°C...
-
Page 3: Pump Designation System
NTG80 NOMAD TRANS-FLO™ PUMP DESIGNATION SYSTEM XXX XX / XXXX / XX / XX / XXX / X / X / X 4 5 6 1 Air Distribution System 2 Liquid Port Size 3 Wetted Parts 7,8 Diaphragms & Valve Balls 9 Valve Seats 11 Fittings 12 Connections 13 ATEX Nomad... - Page 4 NTG80 NOMAD TRANS-FLO™ The NOMAD diaphragm pump is an air-operated, positive displacement, self-priming pump. These drawings show flow pattern through the pump upon its initial stroke. It is assumed the pump has no fluid in it prior to its initial stroke. 1.
-
Page 5: Dimensional Drawings
NTG80 NOMAD TRANS-FLO™ DIMENSIONAL DRAWINGS DIMENSIONS ITEM METRIC (mm) STANDARD (inch) 19.9 30.0 32.4 16.5 12.3 16.8 14.2 12.0 10.2 11.1 PERFORMANCE NTG80 METAL RUBBER-FITTED Height ......... 810 mm (31.9") Width ........432 mm (17.0") Depth ........279 mm (11.0") Est. -
Page 6: Suggested Installation
NTG80 NOMAD TRANS-FLO™ PERFORMANCE NTG80 METAL PTFE-FITTED Height ......... 810 mm (31.9") Width ........432 mm (17.0") Depth ........279 mm (11.0") Est. Ship Weight . Aluminum 53 kg (116 lbs) Stainless Steel ..... 85 kg (187 lbs) Ductile ........91kg (200lbs) Air Inlet ........ -
Page 7: Troubleshooting
NTG80 NOMAD TRANS-FLO™ SUGGESTED INSTALLATION Note: In the event of a power failure, the shutoff valve should be closed, if the restarting of the pump is not desirable once power is regained. TROUBLESHOOTING Pump will not run or runs slowly. Pump air valve freezes. - Page 8 NTG80 NOMAD TRANS-FLO™ EXPLODED VIEW (RUBBER DIAPHRAGMS) EXPLODED VIEW (PTFE DIAPHRAGMS)
- Page 9 NTG80 NOMAD TRANS-FLO™ NTG80 RUBBER-FITTED (ALUMINUM) Stainless Item Description Qty. Aluminum Ductile Iron Steel Air Valve Assembly N15-2012-07 N15-2012-07 N15-2012-07 Air Valve End Cap w/ Guide (Top) N15-2332-23 N15-2332-23 N15-2332-23 Differential Cap N15-2301-23 N15-2301-23 N15-2301-23 Air Valve Snap Ring N15-2651-03 N15-2651-03 N15-2651-03 Air Valve Cap O-ring...
- Page 10 NTG80 NOMAD TRANS-FLO™ NTG80 RUBBER-FITTED...
- Page 11 NTG80 NOMAD TRANS-FLO™ NTG80 PTFE-FITTED (ALUMINUM) Stainless Item Description Qty. Aluminum Ductile Iron Steel Air Valve Assembly N15-2012-07 N15-2012-07 N15-2012-07 Air Valve End Cap w/ Guide (Top) N15-2332-23 N15-2332-23 N15-2332-23 Differential Cap N15-2301-23 N15-2301-23 N15-2301-23 Air Valve Snap Ring N15-2651-03 N15-2651-03 N15-2651-03 Air Valve Cap O-ring...
- Page 12 NTG80 NOMAD TRANS-FLO™ NTG80 PTFE-FITTED...
- Page 13 A JDA Global Company 1645 W. Park Ave., Suite 200 Redlands, CA USA 92373 (909) 798-9532...
