- Page 1 O P E R A T I O N M A N U A L NTG50 NOMAD TRANS-FLO™ AIR-OPERATED • DOUBLE DIAPHRAGM • PUMPS ALUMINUM Models DUCTILE IRON Models 316 STAINLESS STEEL Models A JDA Global Company...
- Page 2 NTG50 NOMAD TRANS-FLO™ CAUTION – SAFETY POINTS TEMPERATURE LIMITS: Neoprene -17.8°C to 93.3°C 0°F to 200°F Buna-N -12.2°C to 82.2°C 10°F to 180°F EPDM -51.1°C to 137.8°C -60°F to 280°F Viton -40°C to 176.7°C -40°F to 350°F ® Santoprene -40°C to 107.2°C -40°F to 225°F ®...
-
Page 3: Pump Designation System
NTG50 NOMAD TRANS-FLO™ PUMP DESIGNATION SYSTEM XXX XX / XXXX / XX / XX / XXX / X / X / X 4 5 6 1 Air Distribution System 2 Liquid Port Size 3 Wetted Parts 7,8 Diaphragms & Valve Balls 9 Valve Seats 11 Fittings 12 Connections 13 ATEX Nomad... - Page 4 NTG50 NOMAD TRANS-FLO™ The NOMAD diaphragm pump is an air-operated, positive displacement, self-priming pump. These drawings show flow pattern through the pump upon its initial stroke. It is assumed the pump has no fluid in it prior to its initial stroke. 1.
-
Page 5: Dimensional Drawings
NTG50 NOMAD TRANS-FLO™ DIMENSIONAL DRAWINGS DIMENSIONS ITEM METRIC (mm) STANDARD (inch) 15.9 24.8 26.3 14.2 10.7 13.5 10.0 10.1 12.3 BSP threads PERFORMANCE NTG50 METAL RUBBER-FITTED Height ......... 668 mm (26.3") Width ........404 mm (15.9") Depth ........343 mm (13.5") Est. -
Page 6: Suggested Installation
NTG50 NOMAD TRANS-FLO™ PERFORMANCE NTG50 METAL PTFE-FITTED Height ......... 668 mm (26.3") Width ........404 mm (15.9") Depth ........343 mm (13.5") Est. Ship Weight Aluminum 33.1 kg (72 lbs) 316 S.S. 51 kg ( 112 lbs) Ductile Iron 49 kg (107.5 lbs) Air Inlet ........ -
Page 7: Troubleshooting
NTG50 NOMAD TRANS-FLO™ SUGGESTED INSTALLATION Note: In the event of a power failure, the shutoff valve should be closed, if the restarting of the pump is not desirable once power is regained. TROUBLESHOOTING Pump will not run or runs slowly. Pump air valve freezes. - Page 8 NTG50 NOMAD TRANS-FLO™ EXPLODED VIEW (RUBBER DIAPHRAGMS) EXPLODED VIEW (PTFE DIAPHRAGMS)
- Page 9 NTG50 NOMAD TRANS-FLO™ NTG50 RUBBER-FITTED Item Description Qty. Aluminum Stainless Steel Ductile Iron Air Valve Assembly N08-2012-07 N08-2012-07 N08-2012-07 Air Valve End Cap w/ Guide N08-2332-01 N08-2332-01 N08-2332-01 Pressure Differential Cap N08-2301-01 N08-2301-01 N08-2301-01 Air Valve Snap Ring N08-2651-01 N08-2651-01 N08-2651-01 Air Valve Cap O-ring N08-3201-52...
- Page 10 NTG50 NOMAD TRANS-FLO™ NTG50 RUBBER-FITTED...
- Page 11 NTG50 NOMAD TRANS-FLO™ NTG50 PTFE-FITTED Item Description Qty. Aluminum Stainless Ductile Iron Steel Air Valve Assembly N08-2012-07 N08-2012-07 N08-2012-07 Air Valve End Cap w/ Guide N08-2332-01 N08-2332-01 N08-2332-01 Pressure Differential Pump N08-2301-01 N08-2301-01 N08-2301-01 Air Valve Snap Ring N08-2651-01 N08-2651-01 N08-2651-01 Air Valve Cap O-ring N08-3201-52...
- Page 12 NTG50 NOMAD TRANS-FLO™ NTG50 PTFE-FITTED NOTE: PTFE diaphragm models assembled with PTFE gasket kit at factory (not shown).
- Page 13 A JDA Global Company 1645 W. Park Ave., Suite 200 Redlands, CA USA 92373 (909) 798-9532...
