OWNER & OPERATOR
INSTRUCTION MANUAL
Model No.
GBS-230A
GBS-270S
IMPORTANT SAFETY NOTICE
To ensure safe and trouble free performance of
your new German knife slicer, we suggest that
all personnel who will use and maintain the
slicer read and understand the manual before
operating the equipment. Should there be any
questions or if we can be of further assistance,
please call us toll free at (800) 500-3519.
TABLE OF CONTENTS
www.turboairinc.com
FOR PARTS AND/OR SERVICE, CONTACT:
GERMAN KNIFE, INC.
1-800-500-3519
www.gkradiance.com
Advertisement
Related Manuals for German Knife GBS-230A
Summary of Contents for German Knife GBS-230A
- Page 1 GBS-270S IMPORTANT SAFETY NOTICE To ensure safe and trouble free performance of your new German knife slicer, we suggest that all personnel who will use and maintain the slicer read and understand the manual before operating the equipment. Should there be any questions or if we can be of further assistance, please call us toll free at (800) 500-3519.
- Page 2 Operating and Service Manual Outer Dimension Specification, Motor Wiring Adjustments Start, When the Machine Operation is Blacked Due to Overloads Cleaning, Changing Saw Blade Parts Description GBS-230A Parts Description GBS-270S Electronic Circuit ------------------------------------------------------------------------------ Troubleshooting--------------------------------------------------------------------------------12 Warranty ----------------------------------------------------------------------------------------13 German Knife Inc 4184 E. Conant St., Long Beach, CA 90808...
- Page 3 12. Always disconnect power supply before removing shrouds, removable guards, covers, doors, fences, panels for servicing, cleaning or any other reason. 13. Use only GERMAN KNIFE parts and accessories properly installed, contact you nearest service agency or The GERMAN KNIFE CORP. for authorized referral assistance.
- Page 4 OUTER DIMENSION GBS-230A GBS-270S...
- Page 5 SPECIFICATION MODEL GBS-230A GBS-270S Dimension 19" x 23.9" x 40" 27.1" x 44.6" x 65.5" Motor AC120Vx1Phasex3/4HP AC120Vx1Phasex1.5HP Weight 88lbs 275lbs Stationary 7.6"x19.7" 11"x30" Table Carriage 13.8"x22.4" 9.5"x13" Loading 14" 22.2" Length of Saw Blade 65.5"(1665mm) 92.9"(2360mm) MOTOR WIRING 1. Interchange of current is made in motor outlet box. Changing instructions are on motor plate or motor outlet box.
- Page 6 (1)Turn the handle of the upper part of the machine clockwise to adjust tension. -GBS-230A: Turn until the sound with a bang occurs twice to three times. (2)Adjust part A while rotating it little by little in order to accurately position Saw Blade.
- Page 7 START This machine has a magnetic safety switch installed to prevent running with the door open to break the electrical connection. ㆍClose the door and latch top and bottom. Insert electrical plug into outlet. ㆍPress the green "ON" button. ㆍUse the red "STOP" button (Located below the start button) when finished. WHEN THE MATHINE'S OPERATION IS BLOCKED DUE TO OVERLOAD The motor has an overload switch in...
- Page 8 CLEANING Clean the machine often and thoroughly at least once a day : ㆍRemove the saw blade, upper wheel door and rolling table from the machine. ㆍClean the machine with a soft brush or cloth and water. Avoid water contact with electrical parts and motor area. ㆍReplace all remove parts when finished.
- Page 9 GBS-230A Tension Assembly Upper Wheel Assembly Door Assembly Safety saw Guard cover Meat pusher Meat Gauge Assembly assembly Lower Wheel Assembly Motor cover Bearing Case Assembly Base & Scrap...
- Page 10 GBS-270S Tension Assembly Upper Wheel Assembly Upper Door Assembly Safety Saw Guard Set Meat Carriage Assembly Meat Gauge Assembly Channel Assembly Lower Door Assembly Scrap Box Bearing Case Assembly Lower Wheel Assembly...
- Page 11 ELECTRONIC CIRCUIT MERIAGE PARTS MODEL : GBS-230A MODEL : GBS-270S...
- Page 12 TROUBLESHOOTING SYMPTOM POSSIBLE CAUSE POSSIBLE SOLUTION 1. Electrical cord is unplugged. 1. Plug in electrical code. Meat Saw does not start. 2. Door is open. 2. Close door. 3. Motor overload has 3. Reset motor overload. tripped. 1. Do not over tighten 1.
- Page 13 Radiance Heavy Duty Microwaves- HD Series (TMW-1200HD, TMW-1800HD) Any part covered under this warranty that is found by German Knife / Radiance to have been defective within the above time period is limited to the repair or replacement, including labor charges, of defective parts or assemblies.
