HaWeKo MIK250 Installation Instructions

HaWeKo
More than only Consoles!
Brunnenstr. 55
70372 Stuttgart
Tel: +49 711 / 794821 03
Fax: +49 711 / 794821 05
Mail: info@HaWeKo24.de
Web: www.HaWeKo24.de
Caution:
Due to safety reasons pay attention to the course of existing, also non-visible cables, wires and other
components which are situated in the installation area!
Note:
The console and the components are to be installed in such a way that for the passengers no dangers
of injury (e.g. by sharp edges) develops.
Installation Instructions for Telephone
Mitsubishi Colt, MY 06/04-
Item-
No.:
Console
MIK250 / 255

Illustration 1:

Move the ashtray from the right beverage holder to
the left beverage holder.

Illustration 2:

Remove the right beverage holder with a flat object.

Illustration 3:

Attach the beverage holder but do not let click into
place.
Place the console into the beverage holder.
Adjust the position of the console.
as at March-04
Page 1 of 2
