- Page 1 Instruction Manual Battery Pack Installation Xtreme Performance Rack/Tower Series (XPRT) Date: 2007-05-18 Page: 1 of 11 Version 1.1...
- Page 2 Safety Warning and Caution! Risk of Electric Shock, This Battery Pack contains batteries inside, Energized parts and Hazardous electrolyte are harmful to personnel. Hazardous voltage may exist between battery terminals and ground. Test before touching. This Battery Pack is designed for installation in a controlled environment. To reduce the risk of fire, replace only with the same type and rating of fuse or circuit breaker.
- Page 3 Battery Pack Installation Instructions 1. Installing the left Slide Rail on to the Post of Rack. 2. Installing the right Slide Rail on to the Post of Rack. Date: 2007-05-18 Page: 3 of 11 Version 1.1...
- Page 4 3. Placing the Battery Pack on to the Slide Rails. 4. Fastening the left Bracket. 5. Fastening the right Bracket. Date: 2007-05-18 Page: 4 of 11 Version 1.1...
- Page 5 6. Slide the Battery Pack into position and using the screws to fasten the Brackets to the Front Posts of The Rack. 7. Top View of the installed Battery Pack on the Rack. Date: 2007-05-18 Page: 5 of 11 Version 1.1...
- Page 6 8. The Close-up View of the Bracket on the Rack Post. Date: 2007-05-18 Page: 6 of 11 Version 1.1...
- Page 7 Instructions for Connecting the Battery Pack(s) First disconnect the UPS from mains and loads before attempting an External Battery Cabinet installation. Both Battery circuit breakers (located in the back) must be “OFF”. Remove the Steel Cover that over the Battery Connectors on Rear Panel of External Battery Pack, and on Rear Panel of UPS.
- Page 8 Rear Panel View of 700VA ~ 1500VA UPS and EBP (12 pcs Batteries): Date: 2007-05-18 Page: 8 of 11 Version 1.1...
- Page 9 Rear Panel View of 2000VA ~ 3000 VA UPS & EBP (12 pcs Batteries): Make sure the Breaker on Battery Pack is in “OFF” Position. Date: 2007-05-18 Page: 9 of 11 Version 1.1...
- Page 10 10. Connect the Electrical Connections between UPS and Battery Pack. The EBP Connector is keyed so as to insure correct Polarity. 11. Then, Turn the Breaker on Battery Pack to “On” Position. Obtaining Service/Warranty If the UPS requires Service Date: 2007-05-18 Page: 10 of 11 Version 1.1...
- Page 11 1. Use the TROUBLESHOOTING section to eliminate obvious causes. 2. Verify there are no circuit breakers tripped. A tripped circuit breaker is the most common problem. 3. Call your dealer for assistance. If you cannot reach your dealer, or if they cannot resolve the problem call or fax Xtreme Power Technical Support at the following numbers at 800.582.4524.
- Page 12 Limited Three Year Warranty XPRT three Series UPS products are warranted free from defects in material and workmanship for years from date of purchase. This warranty is limited to repairing or replacing, at Xtreme Power’s sole option, any defective component, circuit board or module contained within the product, only when it is returned with an Xtreme Power Return Material Authorization (RMA) number to Xtreme Power.
