- Page 1 BP-XR2U480A External Battery Pack User & Installation Manual www.xpcc.com | © 2016 Xtreme Power Conversion Corporation. All rights reserved. (Rev 7/14/16)
-
Page 2: Table Of Contents
BP-XR2U480A User’s Manual External Battery Pack Table of Contents Product Overview..................3 Assembly......................3 Dismount the Cabinet Shell......................3 Battery Installation and Connection....................5 Fuse in Battery Pack........................6 4 Post Rail Mounting..................7 Multiple Battery Pack Connections...............8 Installation and Setup..................8 Unpacking & Inspection........................8 Selecting Installation Position......................8 Enclosure Installation........................9... -
Page 3: Product Overview
Product Overview The BP-XR2U480A battery pack dimension is 442W x 1086D x 86H mm (17.4 x 42.8 x 3.4 in) and unit weight is 88.5 kgs (195 lbs). It includes battery connection cables, breaker, fuse, terminal, etc, with a maximum capacity of 40 pcs 12V/5AH batteries inside. - Page 4 BP-XR2U480A User’s Manual External Battery Pack Xtreme Power Conversion Corporation Page 4...
-
Page 5: Battery Installation And Connection
BP-XR2U480A User’s Manual External Battery Pack Battery Installation and Connection Users need 40 pcs batteries, divide into 2 groups. Each group has 20 pcs batteries in series, as (BAT+ N BAT-) shown below. 40 pcs batteries installation and connection: Each battery tray fit 10pcs batteries, then connect the batteries as shown in below pictures. -
Page 6: Fuse In Battery Pack
BP-XR2U480A User’s Manual External Battery Pack 40 pcs batteries connection After the battery installation and connection done, check if BAT+ to N & N to BAT- voltages are correct with multi- meter or other equipment. Install the cover if the voltages are correct. -
Page 7: Post Rail Mounting
BP-XR2U480A User’s Manual External Battery Pack 4 Post Rail Mounting Xtreme Power Conversion Corporation Page 7... -
Page 8: Multiple Battery Pack Connections
MORE BATTERY CELL LINKS IN EACH TIER. DO NOT RECONNECT THESE LINKS AND DO NOT CLOSE THE BATTERY CIRCUIT BREAKER UNLESS ALL CONNECTIONS ARE PROPERLY CHECKED AND APPROVED. R91-20K to BP-XR2U480A battery connection Installation and Setup Note: Before installation, please inspect the unit. Be sure that nothing inside the package is damaged. Please keep the original packing material in a safe place for future use. -
Page 9: Enclosure Installation
BP-XR2U480A User’s Manual External Battery Pack 1. Do not block the air-flow to the ventilation openings of the unit. 2. Please ensure the installation site environmental conditions are in accordance with the unit’s working specifications to avoid overheat and excessive moisture.
