ASAHI 94 Series User Manual

ASAHI/AMERICA, INC 655 ANDOVER STREET LAWRENCE, MA. 01843 TELEPHONE 800-343-3618
Series 94 GEN II Modulating Electric Actuator
CAUTION: Proper voltage must be supplied to actuator.
CAUTION: If 120VAC & 220VAC models are PLC driven, output contacts of PLC should be rated at a
minimum of 1.5 times required input voltage of actuator
NOTE: To conform to various electrical codes, a green grounding screw has been installed (on the
baseplate) inside of actuator.
Terminal strip is suitable for up to #14 AWG wire, and should be wired as per the attached diagrams or
the wiring diagram affixed inside of actuator cover.
NOTE: We recommend sealing conduit openings on units installed outdoors or exposed to large
We also recommend the heater and thermostat option in these applications.
Model
A94
B94
Note: Amp rating is considered locked rotor
For outdoor or wet locations it is recommended prior to replacing the cover that the top shaft seal be
cleaned and coated with silicone grease. Also clean shaft and lightly coat seal area of shaft with
silicone grease.
Push down on handle (Part #34) and rotate within labeled limits.
To re-engage simply rotate actuator handle in opposite direction until it moves up and re-engages.
CAUTION: The manual override should only be used when there is no power applied to
actuator. When power is restored the actuator will automatically resume normal operation.
Allow 4.75 inches clearance for cover removal.
Need more detailed information? Download a complete IOM at our website.
File: Series 94 GEN II Modulating User Manual
temperature swings (15ºF or more).
120 Vac 220 Vac
Torque Amp Duty Amp
(in/lbs) Draw Cycle Draw
150 0.5 100% 0.4 100% 4.0 75%
300 0.8 75% 0.6 75% 4.0 75%
Duty cycles are for ambient temperature (73

Manual Override Operation

Reference Drawing #279QM
Rev: B
24 vac Cycle
Time per
90
Duty Amp Duty
Degrees
Cycle Draw Cycle
(Seconds)
5
5
°F)
9/30/2015
Weight
(lbs)
3.5
3.5
www.asahi-america.com
Page 1 of 4
