Vibe OPTIVW6-V8 Manual

Volkswagen & variants speaker upgrade kit

Volkswagen & variants speaker upgrade kit

SPECIFICATION

Configuration

2-way component

Speaker Size

6.5" (165mm)

Peak/RMS Power

270W/90W

Sensitivity

94dB

Frequency Response

54Hz - 25kHz

Impedance

4Ω

Mounting Depth

2.4" (61mm)

Mounting Diameter

5.6" (142mm)

Recommended Amp

POWERBOX65.4M-V7

OPTIVW6-V8

High Efficiency OEM Speaker System

Table of Contents

Do you have a question about the OPTIVW6-V8 and is the answer not in the manual?

Page 1 OPTIVW6-V8 Volkswagen & variants speaker upgrade kit SPECIFICATION Configuration 2-way component Speaker Size 6.5” (165mm) Peak/RMS Power 270W/90W Sensitivity 94dB Frequency Response 54Hz - 25kHz Impedance 4Ω Mounting Depth 2.4” (61mm) Mounting Diameter 5.6” (142mm) High Efficiency OEM Speaker System Recommended Amp POWERBOX65.4M-V7...
Page 2 • Recommended VIBE dampening roller CLDR-V7. Contact your authorised VIBE for more information. • Apply the disc of VIBE wave diffuser over the top of the sound deadening material. • Attach the vehicle specific adaptor ring to the door / door card.
Page 3 • Insert the adjustable silicone speaker baffle into the adaptor ring. • Attach the speaker wiring loom adaptor to the vehicle speaker wiring ensuring correct polarity is observed and attach to the speaker terminals. • Fit the OPTI6C speaker into the silicone speaker baffle and align the screw holes before securing with the supplied screws.
Page 4 Fabia Škoda Citigo 2012> Škoda Citigo All VIBE products carry a full 12 month warranty, valid from the date of the MAKE MODEL YEAR RANGE FROM / TO MAKE MODEL original receipt and proof of purchase (UK only). The online warranty card should be completed within seven days of the original purchase date. The...
