Wenger Tourmaster Side Rails Assembly Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Visit the Tourmaster Choral Risers
web page at www.wengercorp.com for detailed instructions and videos.
CONTENTS
Parts List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Fasteners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Side Rail Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Assemble Slide Leg To Side Rail Leg . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Assemble Side Rail Legs For All Risers With a 4th Step Addition . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Assemble Side Rail Legs For All Risers Without a 4th Step Addition . . . . . . . . . . . . . . . . . . . . . . . . .7
Assemble The Side Rail Brackets To the Side Rails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Assemble The Swing Brackets To The Side Rails . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
To Attach Side Rails To The Riser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Note: Side Rails will fit on both the 3-step and 4-step Tourmaster Choral Risers.
Note: Please read and understand the Tourmaster Side Rail Assembly Instruction before
assembling the Side Rails parts.
Note: Remove all items from the shipping carton and arrange them in their approximate final
position. Refer to the illustrations on the following pages. If you need additional information,
contact the Wenger Corporation using the information below.
©Wenger Corporation 2014
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: 800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com
Tourmaster
3-Step Model shown with optional
Side and Back Rails
Printed in USA 01/14
Assembly Instructions
Side Rails
®
Part #024F148-05

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Tourmaster Side Rails and is the answer not in the manual?

Questions and answers

Related Manuals for Wenger Tourmaster Side Rails

Summary of Contents for Wenger Tourmaster Side Rails

  • Page 1: Table Of Contents

    Refer to the illustrations on the following pages. If you need additional information, contact the Wenger Corporation using the information below. ©Wenger Corporation 2014 Printed in USA 01/14 Part #024F148-05 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448 Questions? Call..USA: 800-4WENGER (493-6437) • Worldwide: 1-507-455-4100 • www.wengercorp.com...

  • Page 2: Parts List

    PARTS LIST Item Qty* Description Side Rail Bracket Capscrew, 5/16-18x2” Swing Bracket Flat Washer, 5/16” Locknut, 5/16-18 Side Rail Capscrew, 5/16-18x1-3/4” Side Rail Leg Plug, Square, 1-1/4” Slide Leg * Quantity is for a set of Side Rails. FASTENERS 2” (2) Capscrew, 5/16-18x2”...

  • Page 3: Side Rail Assembly

    SIDE RAIL ASSEMBLY ASSEMBLE SLIDE LEG TO SIDE RAIL LEG Note: The position of the (10) Slide Leg depends upon the Tourmaster Riser model. One of three clearance holes in each Slide Leg is used to fasten the Slide Leg to the (8) Side Rail Leg with a single (7) Capscrew, 5/16-18x1-3/4 inches long.
  • Page 4 SIDE RAIL ASSEMBLY CONTINUED ASSEMBLE SLIDE LEG TO SIDE RAIL LEG ( CONTINUED Use the Center Hole for the following models: • For 6-foot wide 3-step Tourmaster Risers with 18-inch deep steps • For 6-foot wide Tourmaster Risers with 18-inch deep steps and the 4th step addition installed •...
  • Page 5 SIDE RAIL ASSEMBLY CONTINUED ASSEMBLE SLIDE LEG TO SIDE RAIL LEG ( CONTINUED 2. Insert a (7) Capscrew, 5/16-18x1-3/4 inch long into the (8) Side Rail Clearance Hole. 3. Using two one-half inch open end wrenches, tighten a (5) Locknut, 5/16-18, on the Capscrew. (8) Side Rail Leg (5) Locknut, 5/16-18 Side Rail Leg Clearance Hole...

  • Page 6: Assemble Side Rail Legs For All Risers With A 4Th Step Addition

    SIDE RAIL ASSEMBLY CONTINUED ASSEMBLE SIDE RAIL LEGS FOR ALL RISERS WITH A TH STEP ADDITION To assemble the (8) Side Rail Leg to a (6) Side Rail for all Risers with the 4th Step Addition, do as follows. 1. Slide the (8) Side Rail Leg onto (6) Side Rail with the (10) Slide Leg oriented to the left side. 2.

  • Page 7: Assemble Side Rail Legs For All Risers Without A 4Th Step Addition

    SIDE RAIL ASSEMBLY CONTINUED ASSEMBLE SIDE RAIL LEGS FOR ALL RISERS WITHOUT A TH STEP ADDITION To assemble the (8) Side Rail Leg to a (6) Side Rail for all Risers without the 4th Step Addition, do as follows. 1. Slide the (8) Side Rail Leg onto (6) Side Rail with the (10) Slide Leg oriented to the left side. 2.

  • Page 8: Assemble The Side Rail Brackets To The Side Rails

    SIDE RAIL ASSEMBLY CONTINUED ASSEMBLE THE SIDE RAIL BRACKETS TO THE SIDE RAILS 1. Place the (1) Side Rail Bracket onto each (6) Side Rail as shown in the illustration below. Align the clearance holes in each bracket to the clearance holes in each (6) Side Rail. Note: Make sure that the S shape or open channel of the (1) Side Rail Bracket is on the same side as the (10) Slide Leg.

  • Page 9: Assemble The Swing Brackets To The Side Rails

    SIDE RAIL ASSEMBLY CONTINUED ASSEMBLE THE SWING BRACKETS TO THE SIDE RAILS 1. Position two (3) Swing Brackets on a (6) Side Rail on the side away from the (1) Side Rail Bracket open channel with two (4) Flat Washers inserted between the Swing Bracket and Side Rail Bracket, as shown in the illustration below.

  • Page 10: To Attach Side Rails To The Riser

    TO ATTACH SIDE RAILS TO THE RISER Note: Back Rails are required in order to attach Side Rails. 1. Place the Side Rail in the approximate attachment position with the leg extension resting on the floor. Slide the Side Rail towards the Back Rail until the Side Rail Bracket fits over the Back Rail as shown below.
  • Page 11 TO ATTACH SIDE RAILS TO THE RISER CONTINUED 2. Rotate the Upper and Lower Swing Brackets Back Rail to a vertical position, locking the Side Rail to Side Rail the Back Rail. Upper Swing Bracket Lower Swing Bracket 3. Lift and hold the front of the riser off the floor and slide the Lower Leg Cradle Bracket under the Step Support Frame.
  • Page 12 TO ATTACH SIDE RAILS TO THE RISER CONTINUED 4. A Rail Lock Down Bracket is used to reduce movement of the Back Rail when using the Side Rail. Thread the Right and Left Hooks into the Turnbuckle. Engage the Back Rail and Top Step with the Rail Lock Down Bracket Hooks as shown below.
