- Page 1 INNOVATION IN MAGNETICS OM-2497/5 Operation Manual for Mag670 Single Axis Magnetic Field Sensor www.bartington.com...
-
Page 2: Table Of Contents
BARTINGTON INSTRUMENTS Table of Contents 1. About this Manual 1.1. Symbols Glossary 2. Safe Use 3. Introduction to the Mag670 4. Installing the Mag670 4.1. Siting the Sensor (Environment Recommendations) 4.2. Cable Recommendations 4.3. Pre-Installation Tests 4.4. Mounting Recommendations 4.5. Post Installation Testing 5. -
Page 3: About This Manual
2. Safe Use WARNING: These products are not qualified for use in explosive atmospheres or life support systems. Consult Bartington Instruments for advice. WARNING: Environmental and electrical specifications should not be exceeded. To prevent irreparable damage, electrostatic discharge (ESD) protection and precautions must be used when handling the unpackaged sensor electronics board. -
Page 4: Introduction To The Mag670
BARTINGTON INSTRUMENTS 3. Introduction to the Mag670 The Mag670 is a single-axis fluxgate sensor that provides highly linear magnetic response and low hysteresis. Each instrument consists of a single, feedback-stabilised, fluxgate sensing element arranged along the length of the enclosure, which is orientated to point away from the unit’s connector. -
Page 5: Pre-Installation Tests
For this reason the cable should be limited to a maximum length of 600 metres. Bartington Instruments can supply cables for connection of the sensor to the PSU1, Magmeter, SCU1 and Spectramag-6 data acquisition and power supply units. -
Page 6: Post Installation Testing
Degaussing the sensor can reverse such an effect. Note: The Mag670 is designed to have an extremely low magnetic hysteresis. However, Bartington Instruments recommends your sensor is not subjected to magnetic fields greater than their stated measuring range for extended periods as this could alter the DC offset. -
Page 7: Troubleshooting
The most likely causes of failure, and their solutions, are detailed in the following table. In the event of any apparent malfunction beyond those described in the table below, please email service@bartington.com, or telephone the Bartington Instruments service team on +44 (0)1993 706565. Causes of Failure... -
Page 8: Calibration
Refer to the manufacturer’s Material Safety Data Sheet (MSDS) for information on using this chemical safely. 7.2. Calibration Return the Mag670 to Bartington Instruments for calibration at the recommended intervals. Refer to the Calibration Certificate for further details. 8. End of Life Disposal This product (electrical and electronic equipment) should not be placed in municipal waste. - Page 9 ®The copyright of this document is the property of Bartington Instruments Ltd. Bartington is a registered trademark of Bartington Instruments Limited in the following countries: Australia, Brazil, Canada, China, European Union, India, Israel, Japan, Mexico, New Zealand, Norway, Russia, Singapore, South Korea, Switzerland, Turkey, United Kingdom, United States of America and Vietnam.
