- Page 1 INNOVATION IN MAGNETICS OM3836/2 Operation Manual for Mag646 Single Axis Unpackaged Magnetic Field Sensor www.bartington.com...
-
Page 2: Table Of Contents
2. Safe Use 3. Introduction 4. General Description 5. Connections 5.1. Cable Recommendations 5.2. Connection to Power Supply/Acquisition Unit 6. Using the Mag646 6.1. Mag646 Operation 6.2. Electromagnetic Compatibility 7. Troubleshooting 8. Care and Maintenance 8.1. Calibration 9. End of Life Disposal... -
Page 3: About This Manual
BARTINGTON INSTRUMENTS 1. About this Manual This manual provides the information necessary to help Mag646 customers connect, install and operate, the Mag646 magnetic field sensor. Technical specifications of the products, including power supply requirements and analogue output details, can be found in DS3836, while outline drawings of sensor head, electronics board... -
Page 4: Introduction
BARTINGTON INSTRUMENTS 3. Introduction The Mag646 is an unpackaged single-axis fluxgate sensor that provides highly linear magnetic response and low hysteresis. The sensor consists of a single, feedback-stabilised, fluxgate sensing element arranged along one of two directions, in line with the PCB or perpendicular to the long side of the PCB. -
Page 5: Connection To Power Supply/Acquisition Unit
Caution: When providing your own power supply, do not exceed the voltage rating, provide sufficient current, and ensure correct polarity is respected, see DS3836. Caution: Connect the Mag646 electronics board before the supply is energized, as this prevents high surge currents which could cause damage. -
Page 6: Electromagnetic Compatibility
BARTINGTON INSTRUMENTS 6.2. Electromagnetic Compatibility Note: The Mag646 sensors are not shielded for immunity from, or emission of, electromagnetic fields. Note: The Mag646 sensors are intended for integration into other systems. Ensure these meet the appropriate level of shielding. 7. Troubleshooting The sensor is unlikely to suffer any defects in normal use: no internal components are serviceable. -
Page 7: Care And Maintenance
(at least twice the breakthrough frequency). 8. Care and Maintenance Surface dirt contamination on the Mag646 probe should be removed using a mild detergent solution only. Electronics should be cleaned with an antistatic cloth only. ESD protection should be used when handling the Mag646 electronics board, to prevent irreparable damage. - Page 8 ®The copyright of this document is the property of Bartington Instruments Ltd. Bartington is a registered trademark of Bartington Instruments Limited in the following countries: Australia, Brazil, Canada, China, European Union, India, Israel, Japan, Mexico, New Zealand, Norway, Russia, Singapore, South Korea, Switzerland, Turkey, United Kingdom, United States of America and Vietnam.
