Important Mounting Instructions
When wall mounted, the black box containing the
VAE processor must be securely attached to the
wall in accordance with the installation instructions.
FAILURE TO FOLLOW INSTALLATION
INSTRUCTIONS MAY RESULT IN INJURY.
These instructions cover the installation of Wenger's VAE
(Virtual Acoustic Environments) electronics package in new installations
where the room contains all necessary internal components like speakers,
microphones and VAE control panel.
Contents
Overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Black Box Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
©Wenger Corporation 2019
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Questions? Call.....USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com
!
CAUTION
Printed in USA 2019-01
Installation Instructions
SoundLok
VAE
Installation
®
®
®
Part #270A586-03
Advertisement
Related Manuals for Wenger SoundLok VAE
Summary of Contents for Wenger SoundLok VAE
- Page 1 Black Box Installation ....... . 3 ©Wenger Corporation 2019 Printed in USA 2019-01 Part #270A586-03 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448 Questions? Call..USA: (800) 4WENGER (493-6437) • Worldwide: +1-507-455-4100 • wengercorp.com...
- Page 2 Most installations will allow the black box to be located in its preferred position, sitting on the top of the VAE equipped Wenger SoundLok room. In applications where that space is not available or desirable, the black box can be mounted to the wall on the side of the room.
-
Page 3: Black Box Installation
Black Box Installation Attach a hanger bracket to both sides of the rack using two #10-16 x 0.75" self drilling screws in each side. Use the bottom set of holes in the mounting brackets for Top Set of Holes for mounting the rack to the ceiling. - Page 4 Black Box Installation (continued) 2. Install the flash memory card (connector end first) into the slot in the back of the VAE processor labeled COMPACT FLASH. It will fit into this slot in only one orientation. The contacts will engage during the last 0.125"...
- Page 5 Black Box Installation (continued) 5. Connect the microphone cables. Locate the microphone panel located toward the left-hand side as entering the room. Connect a microphone cable between the connector on the top of this panel and the jack labeled "MICROPHONE 1" on the back of the VAE processor inside the black box.
- Page 6 Black Box Installation (continued) 7. Install four clip nuts into the four available holes in the front panel of the black box. Install them with the "nut" portion inside the black box. Using these clip nuts, install the processor into the black box with the four screws and washers provided with the VAE processor.
- Page 7 Black Box Installation (continued) 9. Be sure the VAE system power switch on the power panel is in the OFF position. Plug the main black box power cable into the mating connector on any other available panel. Secure this cable to the adjacent ceiling or wall panel using a cable clip and self-drilling screw positioned within 6"...
