- Page 1 Trim Saver Assembly Instructions CS-12 Manual Version 2.3...
- Page 2 1. Remove nuts and bolts from the underside of the vacuum and control box. 2. Remove vacuum and control box. 3. Place Twister T4 Leaf Trimmer on the Twister T4 Leaf Collector stand. Additional Requirements 4. Connect the separator to the T4 with collector hose.
- Page 3 COMPONENT PARTS FASTENERS KEEP FASTENERS IN LABELLED BAGS, ASSEMBLY INSTRUCTIONS DESCRIBE WHERE EACH PACKAGE IS USED. PART NO DESCRIPTION 23-0198-00 HOSE SADDLE 23-0199-00 6 INCH HOSE 23-0202-00 VACUUM SEPARATOR 23-0204-00 CART HANDLE 23-0205-00 SADDLE SUPPORT CS-12 23-0206-00 MOTOR SUPPORT 23-0241-00 SEPARATOR GASKET 23-0208-00 LID HOLDER...
- Page 4 FASTENER BAG “A” FASTENER BAG “B” 5/16 Star Lock Washer Ensure holes are on this side FASTENER BAG “C” 5/16 Star Lock Washer FASTENER BAG “D” FASTENER BAG “E” FLIP 90° Ensure post is oriented correctly...
- Page 5 FASTENER BAG “G” FASTENER BAG “F” 5/16 Star Lock 5/16 Star Lock Washer Washer FASTENER BAG “H” 1/4-20 x 1” 1/4 Flat Washer 1/4-20 Nut Silicone Washer...
- Page 6 REMOVE CLEANING FLANGE TO CLEAN SEPARATOR ENSURE THE BIN LID GASKET IS PROPERLY SEATED ON THE LID, AND FLUSH TO THE TOP OF THE BIN AFTER ALL LATCHES ARE ENGAGED. Sliding hose cuffs over the vacuum separator may be difficult. Apply isopropyl alcohol or dish soap to help slide the hose on.
- Page 7 6” Hose Hose Saddle Saddle Support Cleaning Flange Vacuum Separator Filter Bag Lid Holder Filter Clamp Bin Lid Filter Adapter Motor Support Impeller Housing Vacuum Motor Caster Cart Handle...
