- Page 1 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Enigma Veyron Loudspeaker User Guide EV-1D-1.1...
-
Page 2: Table Of Contents
KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Table of content Preface Introduction to the Enigma Veyron System Part list Unpacking Loudspeaker Connection Optimization Specifications Dimensions Warranty... -
Page 3: Preface
KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Preface Congratulations, You are now the owner of a Kharma Enigma Veyron Loudspeaker. Your new loudspeaker, properly installed, will give you all the satisfaction and enjoyment you expect from Kharma. As with any high quality product, special care must be taken to install your loudspeaker. -
Page 4: Introduction To The Enigma Veyron System
This time fully new engineered Kharma drivers are the basis of the Enigma Veyron, as well as a new cabinet, materials, internal cable technology and more. We decided to offer the whole package to drive the full Enigma Veyron as well. - Page 5 Moreover, Kharma created the largest Diamond cone surface ever used in a loudspeaker. To create extreme resolution and dispersion for the upper mid and lower high frequency Kharma has used 4 x 50 mm diamond tweeters. For the ultimate clear high frequencies, far beyond hearing, four Diamond tweeters of 25 mm are being used.
-
Page 6: Part List
KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Part list The Enigma Veyron Loudspeaker comes in 2 crates for a pair: The two crates contain: 2 x EV-1D-1.1 loudpeaker 2 x Top cover for loudspeaker 8 x M10 Bolts 2 x Tilting accessory... -
Page 7: Unpacking Loudspeaker
KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Unpacking Loudspeaker Opening the crate Upon opening the crate, inspect the crate carefully for any sign of transport damage. If there is damage, immediately call your dealer or the trucking firm that made the delivery. Do not delay in reporting the damage. - Page 8 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Step 2: Unscrew all side panels Step 3: Keep the speaker fixated Do not unscrew the panel that is fixated on the loudspeaker. This is required to tilt the loudspeaker. DO NOT unscrew...
- Page 9 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Step 4: Lift loudspeaker from pallet The openings indicated with the green arrows can be used in combination with a hoist structure or forklift. Please always check the balance of the hoist structure before lifting the loudspeaker completely.
- Page 10 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Step 6: Apply protection During tilting there will be a heavy force applied on the floor. To protect as well the floor as the stand, please use a protective plate on the floor. When tilting more than 500 kg will divided over only two points, please Important make sure the floor is protected properly.
- Page 11 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Step 8a: Tilting with forklift truck The crate has one beam placed in the length of the speaker, such that a forklift truck can be shoved under the crate at the top of the speaker.
- Page 12 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Step 9: Start tilting The crate part should stay on the loudspeaker until it’s standing upright. The loudspeaker could start sliding, when tilting. Please make sure there is somebody to prevent the sliding. Step 10: Tilt until loudspeaker is upright...
- Page 13 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Step 11: Remove crate part The crate part is fixated at the top with four bolts. Remove the bolts, while holding the crate part. When the crate part is loose, lift the part from the loudspeaker.
- Page 14 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Step 14: Remove protective plate and position loudspeaker The protective plate can be removed underneath the loudspeaker by tilting the loudspeaker a bit. The loudspeaker can now be positioned more precisely around with the supplied movers .
- Page 15 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Step 14: Level speaker The speaker has a stand with integrated Diamond suspension. The discs are already part of the stand and don’t need adjustments. A hex key can be used to level the speaker. By inserting the hex key at the top of the stand and turning the hex key, the stand leg moves up or downwards.
-
Page 16: Connection
KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Connection At the rear of the Enigma Veyron Loudspeaker the Kharma Connection Terminals can be found. Before using the loudspeakers, remove the wires that shortcut the connectors. These wires are placed so the units will not move during transport and have less chance of being damaged. -
Page 17: Optimization
KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Optimization Room Acoustics A good listening room has just the right amount of reflection and absorption. The performance of any loudspeaker depends upon the speaker’s location in the room and the acoustical conditions in that part of the room. - Page 18 KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Positioning your Enigma Veyron Loudspeaker As said before we recommend experimenting with loudspeaker placement in order to obtain the best spectral balance, openness and perception of depth. For good results, the loudspeakers should be no closer than 45 cm from the rear wall with at least 70 cm to the side walls.
- Page 19 If you have been unsuccessful in locating the specific source of trouble (or if you have located it, but have been unable to correct it): Consult the Authorized Kharma-dealer from whom you purchased the system. Kharma Dealers are audio specialists and can be of great assistance.
-
Page 20: Specifications
Peak power: 2000 Watt Connection Double Kharma Connection Terminal Drivers High-frequency: 4 x 1-inch Diamond concave tweeter High / Mid-frequency: 4 x 2-inch Diamond concave tweeter Mid-frequency 2 x 7-inch Kharma Omega-F Driver Low-frequency: 4 x 11-inch Kharma Omega-F Driver... -
Page 21: Dimensions
KHARMA HIGH-END PRODUCTS BEYOND IMAGINATION Dimensions Dimensions including stand 2273 mm / 89.5 inch Height 558 mm / 22.0 inch Width 922 mm / 36.3 inch Depth Dimensions excluding stand 2179 mm / 85.8 inch Height 420 mm / 16.5 inch Width 790 mm / 31.1 inch... -
Page 22: Warranty
In case of malfunction the customer has to present the Kharma product in its original packing to an authorized dealer. If qualified service appears inevitable, the dealer will ship the product to an appointed service station or to the factory, depending on the required service.
