  • Page 1 User Manual MIO-5391 7th Gen Intel® Core™ H-series (i7/i5/i3/Xeon®*), 3.5" MI/O-Compact SBC, DDR4, Dual HDMI, 48-bit LVDS, 2 GbE, M.2 E Key, mSATA, Fanless, MIOe...
  • Page 2 No part of this manual may be reproduced, copied, translated or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd. Information provided in this manual is intended to be accurate and reliable. How- ever, Advantech Co., Ltd.
  • Page 3 Because of Advantech’s high quality-control standards and rigorous testing, most of our customers never need to use our repair service. If an Advantech product is defec- tive, it will be repaired or replaced at no charge during the warranty period. For out- of-warranty repairs, you will be billed according to the cost of replacement materials, service time and freight.
  • Page 4 Discard used batteries according to the manufacturer's instruc- tions. Technical Support and Assistance Visit the Advantech website at http://support.advantech.com where you can find the latest information about the product. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance. Please have the following information ready before you call: –...
  • Page 5 Packing List Before you begin installing your card, please make sure that the following materials have been shipped:  1 x MIO-5391 SBC  1 x SATA Cable 30cm (p/n: 1700006291)  1 x SATA Power Cable 35cm (p/n: 1700018785) ...
  • Page 6 MIO-5391 User Manual...
  • Page 7 Environmental ................5 Block Diagram................... 5 Board layout: dimensions................6 Figure 1.1 MIO-5391 Mechanical Drawing (Top Side) ....6 Figure 1.2 MIO-5391 Mechanical Drawing (Bottom Side) ... 6 Figure 1.3 MIO-5391 Mechanical Drawing (Coastline)....7 Figure 1.4 MIO-5391 Mechanical Drawing (with Cooler)..... 7 Figure 1.5 MIO-5391 Mechanical Drawing (with Heatsink) ..
  • Page 8 Table B.1: System I/O Ports ............74 DMA Channel assignments ..............74 Table B.2: DMA Channel assignments........74 1st MB memory map................75 Table B.3: 1st MB memory map ..........75 Interrupt assignments ................75 Table B.4: Interrupt assignments..........75 MIO-5391 User Manual viii...
  • Page 9 Chapter General Information This chapter gives background information on the MIO-5391. Sections include:  Introduction  Specifications  Block diagram  Board layout and dimensions...
  • Page 10 Based on numerous demands from embedded applications, Advantech developed an optimized thermal solution for MIO-5391. This makes the possibility of fanless design on this kind of high performance platform. MIO-5391 also embedded SUSI 4.0 and WISE-PaaS/ RMM created by Advantech to monitor and control system operation effectively and remotely.
  • Page 11  Supports up to 9 KB jumbo frames (full duplex) * 802.1as/1588 conformance – Port2: i210 Gigabit Ethernet Controller  Flow Control Support compliant with the 802.3X Specification  Compliant with the 1 Gb/s IEEE 802.3 802.3u 802.3ab Specifications MIO-5391 User Manual...
  • Page 12 – TPM2.0, only support under UEFI mode 1.2.2 OS support MIO-5391 supports Win10 64 bit For further information about OS support of MIO-5391, please Advantech website: http://support.advantech.com.tw/ or contact the technical support center. 1.2.3 Mechanical Specifications  Dimensions: 146 x 102 mm (5.7 x 4 inches) ...
  • Page 13 Storage Temperature: Storage temperature: -40~85°C  Storage Humidity: Relative humidity: 95% @ 60°C It will not be supported in default, please contact to Advantech if this function is needed. Thermal condition need to be considered when setting max frequency. Block Diagram...
  • Page 14 Board layout: dimensions Figure 1.1 MIO-5391 Mechanical Drawing (Top Side) Figure 1.2 MIO-5391 Mechanical Drawing (Bottom Side) MIO-5391 User Manual...
  • Page 15 Figure 1.3 MIO-5391 Mechanical Drawing (Coastline) Figure 1.4 MIO-5391 Mechanical Drawing (with Cooler) Figure 1.5 MIO-5391 Mechanical Drawing (with Heatsink) MIO-5391 User Manual...
  • Page 16 Figure 1.6 MIO-5391 Mechanical Drawing (with Heat Spreader) MIO-5391 User Manual...
  • Page 17 Chapter Installation This chapter explains the setup procedures of the MIO-5391 hard- ware, including instructions on setting jumpers and connecting peripherals, switches and indica- tors. Be sure to read all safety pre- cautions before you begin the installation procedure.
  • Page 18 Jumpers & Switches The MIO-5391 has a number of jumpers that allow you to configure your system to suit your application. The table below lists the functions of the various jumpers. Table 2.1: Jumpers & Switches Auto Power On Setting...
  • Page 19 Locating connectors & block diagram CN31 CN33 CN32 CN24 CN23 CN25 CN27 CN20 CN21 CN22 CN36 CN34 CN18 Figure 2.1 MIO-5391 Connector Locations (Top Side) CN38 CN50 CN48 CN47 CN30 CN49 CN37 CN45 Figure 2.2 MIO-5391 Connector Locations (Bottom Side) MIO-5391 User Manual...
  • Page 20 CN18 CN21 CN22 Figure 2.3 MIO-5391 Connector Locations (Coastline) Setting Jumpers You may configure your card to match the needs of your application by setting jump- ers. A jumper is a metal bridge used to close an electric circuit. It consists of two metal pins and a small metal clip (often protected by a plastic cover) that slides over the pins to connect them.
  • Page 21 Low for VCON on LVDS 2.4.4 Serial Port Voltage Select (J6) Table 2.6: Serial Port Voltage Select (J6) Part Number 1653003260 Footprint HD_3x2P_79 Description PIN HEADER 3x2P 2.0mm 180D(M) SMD 21N22050 Setting Function (1-2) (3-4) * COM3_RI# (5-6) +12V MIO-5391 User Manual...
  • Page 22 SLIDE SW CJS-1201TA1 SMD 3P SPDT P=6.0mm W=2.5mm Setting Function (2->1)* Normal (2->3) Clear COMS 2.4.6 m-SATA/mPCI-E SEL (SW2) Table 2.8: m-SATA/mPCI-E SEL (SW2) Part Number 1600000071 Footprint SW_3P_CJS-1201TA1 Description SLIDE SW CJS-1201TA1 SMD 3P SPDT P=6.0mm W=2.5mm Setting Function (2->1)* mPCI-E (2->3) m-SATA MIO-5391 User Manual...
  • Page 23 Chapter AMI BIOS Setup...
  • Page 24 AMIBIOS has been integrated into many motherboards for over a decade. With the AMIBIOS Setup program, you can modify BIOS settings and control the various sys- tem features. This chapter describes the basic navigation of the MIO-5391 BIOS setup screens.
  • Page 25 BIOS supports your CPU. If there is no number assigned to the patch code, please contact an Advantech application engineer to obtain an up-to-date patch code file. This will ensure that your CPU‘s system status is valid.
  • Page 26 3.1.2 Advanced BIOS Features Setup Select the Advanced tab from the MIO-5391 setup screen to enter the Advanced BIOS Setup screen. You can select any of the items in the left frame of the screen, such as CPU Configuration, to go to the sub menu for that item. You can display an Advanced BIOS Setup option by highlighting it using the <Arrow>...
  • Page 27 This item allows users to set how many processor cores should be active. Enable/Disable AES (Advanced Encryption Standard). MachineCheck Enable/Disable Machine Check. MonitorMWait Enable/Disable MonitorMWait. Intel Trusted Execution Technology Enables utilization of additional hardware capability provided by Intel® Trusted Exe- cution Technology. MIO-5391 User Manual...
  • Page 28 3.1.2.2 Power & Performance CPU – Power Management Control CPU – Power Management Control Options. GT – Power Management Control GT – Power Management Control Options. CPU - Power Management Control MIO-5391 User Manual...
  • Page 29 Platform PL2 Enable Enable/Disable Platform Power Limit 1 programming. Power Limit 4 Override Enable/Disable Power Limit 4 override. C states Enable/Disable CPU Power Management. Power Limit 3 Settings Power Limit 3 Override Enable/Disable Power Limit 3 override. MIO-5391 User Manual...
  • Page 30 CPU Lock Configuration CFG Lock Configure MSR 0xE2[15], CFG Lock bit. Overclocking Lock Enable/Disable Overclocking Lock (BIT 20) in FLEX_RATIO(194) MSR. GT - Power Management Control MIO-5391 User Manual...
  • Page 31 When disabled, AMT BIOS Features are no longer supported and user is no longer able to access MEBx setup. AMT Configuration Configure Intel® Active Management Technology Parameters. ME Unconfig on RTC Clear When Disabled, ME will not be unconfigured on RTC Clear. Firmware Update Configuration Configure Management Engine Technology Parameters. MIO-5391 User Manual...
  • Page 32 ACPI Sleep State Select the highest ACPI sleep state the system will enter when the SUSPEND button is pressed. Lock Legacy Resources Enables or Disables Lock of Legacy Resources. S3 Video Repost Enable or Disable S3 Video Repost. MIO-5391 User Manual...
  • Page 33 Set Parameters of Serial Port 2. Wake On Ring Control Enable/Disable Wake on Ring Function. Hardware Monitor Monitor hardware Status. Watch Dog Timer Configuration Watch Dog Timer Configuration Page. Case Open Detection Enable or Disable Case Open Detect Function. MIO-5391 User Manual...
  • Page 34 Serial Port 1 Configuration Serial Port Enable or Disable Serial Port (COM). Change Settings Select an optimal settings for Super IO device. COM1 Mode COM1 Mode Select. MIO-5391 User Manual...
  • Page 35 Serial Port 2 Configuration Serial Port Enable or Disable Serial Port (COM). Change Settings Select an optimal settings for Super IO device. COM2 Mode COM2 Mode Select. MIO-5391 User Manual...
  • Page 36 Hardware Monitor Watch Dog Timer Configuration Watch Dog Timer Enable or Disable Watch Dog Timer Function. MIO-5391 User Manual...
  • Page 37 Select the TCG2 Spec Version Support. Physical Presence Spec Version Select to Tell O.S. to support PPI Spec Version 1.2 or 1.3. Device Select TPM 1.2 will restrict support to TPM 1.2 devices, TPM 2.0 will restrict support to TPM 2.0 devices. MIO-5391 User Manual...
  • Page 38 3.1.2.7 S5 RTC Wake Settings Wake system from S5 Enable or disable System wake on alarm event. Select FixedTime, system will wake on the hr::min::sec specified. 3.1.2.8 Serial Port Console Redirection MIO-5391 User Manual...
  • Page 39 This item allows users to enable or disable console redirection for Microsoft Windows Emergency Management Services (EMS). Console Redirection This item allows users to configuration console redirection detail settings. 3.1.2.9 Intel TXT Information Intel TXT Information Display Intel TXT information. MIO-5391 User Manual...
  • Page 40 Maximum time the device will take before it properly reports itself to the Host Control- ler. 'Auto' uses default value: for a Root port it is 100 ms, for a Hub port the delay is taken from Hub descriptor. MIO-5391 User Manual...
  • Page 41 3.1.2.11 Network Stack Configuration Network Stack Enable/Disable UEFI Network Stack. 3.1.2.12 CSM Configuration CSM Support Enable/Disable CSM Support. MIO-5391 User Manual...
  • Page 42 Controls the execution of UEFI and Legacy Storage OpROM. Video Controls the execution of UEFI and Legacy Video OpROM. Other PCI devices Determines OpROM execution policy for devices other than Network, Storage, or Video. 3.1.2.13 NVMe Configuration MIO-5391 User Manual...
  • Page 43 3.1.3 Chipset Configuration Select the Chipset tab from the MIO-5391 setup screen to enter the Chipset BIOS Setup screen. You can display a Chipset BIOS Setup option by highlighting it using the <Arrow> keys. All Plug and Play BIOS Setup options are described in this sec- tion.
  • Page 44 X2APIC Opt Out Enable/Disable X2APIC Opt Out Bit. Memory Configuration Max TOLUD Maximum Value of TOLUD. Memory Scrambler Enable/Disable Memory Scrambler support. Force ColdReset Force ColdReset OR Choose MrcColdBoot mode. Memory Remap Enable/Disable Memory Remap above 4GB. MIO-5391 User Manual...
  • Page 45 Select DVMT 5.0 Total Graphic Memory size used by the Internal Graphics Device. Gfx Low Power Mode This option is applicable for SFF only. PM Support Enable/Disable PM Spport. PAVP Enable Enable/Disable PAVP. CD Clock Frequency Select the highest Cd clock frequency supported by this platform. MIO-5391 User Manual...
  • Page 46 LVDS Panel Type This item allow user to select LVDS panel type. 2nd LVDS Backlight Control Switch Backlight Control for PWM or DC mode. DDI Output Type to MIOe Interface Select DDI Output Type (HDMI/DP) connect to MIOe Connector. MIO-5391 User Manual...
  • Page 47 Enable or Disable onboard LAN's PXE option ROM. PCIE Wake Enable or Disable PCIE to wake the system from S5. State After S3 Specify what state to go to when power is re-applied after a power failure (G3 state). MIO-5391 User Manual...
  • Page 48 PCI Express Configuration PCI Express Root Port 5/6/7/8/9/11 PCI Express Port 5/6/7/8/9/11 Settings. SATA and RST Configuration SATA Controller(s) Enable/Disable SATA Device. MIO-5391 User Manual...
  • Page 49 Indicates the maximum speed the SATA controller can support. USB Configuration XHCI Disable Compliance mode Option to disable Compliance Mode. USB Port Disable Override Selectively Enable/Disable the corresponding USB Port from reporting a Device Con- nection to the Controller. MIO-5391 User Manual...
  • Page 50 Security Configuration RTC Lock Enable will lock bytes 38h-3Fh in the lower/upper 128-byte bank of RTC RAM. BIOS Lock Enable or Disable the PCH BIOS Lock Enable feature. HD Audio Configuration MIO-5391 User Manual...
  • Page 51 3.1.4 Security Select Security Setup from the MIO-5391 Setup main BIOS setup menu. All Security Setup options, such as password protection and virus protection are described in this section. To access the sub menu for the following items, select the item and press <Enter>:...
  • Page 52 Enables or disables boot with initialization of a minimal set of devices required to launch active boot option. Has no effect for BBS boot options. New Boot Option Policy Controls the placement of newly detected UEFI boot options. MIO-5391 User Manual...
  • Page 53 This item allows you to save the changes done so far as user defaults. Restore User Defaults This item allows you to restore the user defaults to all the options. Boot Override Boot device select can override your boot priority. MIO-5391 User Manual...
  • Page 54 MIO-5391 User Manual...
  • Page 55 Chapter MIOe Installation...
  • Page 56 Here is the quick installation guide for our thermal design and MIOe module installation. Quick Installation Guide There is a Heatsink/Cooler (or optional heatspreader) in the white box inside the package, and please assembly it by following explosion drawing. 4.1.1 Cooler MIO-5391 User Manual...
  • Page 57 4.1.2 Heatsink MIO-5391 User Manual...
  • Page 58 4.1.3 Heatspreader MIO-5391 User Manual...
  • Page 59 Appendix Pin Assignments This appendix contains informa- tion of a detailed or specialized nature. Sections include:  Jumper and Connector Tables...
  • Page 60 SATA CN30 MIOe CN31 SMBus CN32 Smart FAN CN33 Inverter Power Output CN34 48-bit LVDS Panel CN36 HDMI CN37 M.2 E Key CN38 COM2 CN45 Front Panel CN47 Mini PCIE CN48 GPIO CN49 SIM Card CN50 GPIO MIO-5391 User Manual...
  • Page 61 (3-5) (3-4) +12V Table A.5: J4 LVDS VCON Setting Part Number 1653000014 Footprint HD_2x2P_79 Description PIN HEADER 2x2P 2.00mm 180D(M) SMD 21N22050 Setting Function (1-2)* 3.3V High for VCON on LVDS (1-3) Low for VCON on LVDS MIO-5391 User Manual...
  • Page 62 SLIDE SW CJS-1201TA1 SMD 3P SPDT P=6.0mm W=2.5mm Setting Function (2->1)* Normal (2->3) Clear COMS Table A.8: SW2 m-SATA/mPCI-E SEL Part Number 1600000071 Footprint SW_3P_CJS-1201TA1 Description SLIDE SW CJS-1201TA1 SMD 3P SPDT P=6.0mm W=2.5mm Setting Function (2->1)* mPCI-E (2->3) m-SATA MIO-5391 User Manual...
  • Page 63 Table A.10: CN2 DC JACK Part Number 1652005278 Footprint PJ_3P_2DC-0005 Description POWER JACK 3P 2.5mm 90D(M) DIP 2DC-0005B100 Pin Name +VIN Table A.11: CN4 Battery Part Number 1655005427-01 Footprint WF_2P_49_53398-0271 Description WAFER 2P 1.25mm 180D(M) SMD 53398-0271 Pin Name +3.3V MIO-5391 User Manual...
  • Page 64 DSR# RTS# CTS# Table A.13: CN6 SODIMMDDR4_260 Part Number 1651002909-02 Footprint SODIMMDDR4_260P_AS0A826-HARB Description DDR4 SODIMM 260P/0.5mm/LCP/RA/G10u/S/BK/H9.2/RVS Pin Name Table A.14: CN7 SODIMMDDR4_260 Part Number 1651002908-01 Footprint SODIMMDDR4_260P_AS0A826-H2RB Description DDR4 SODIMM H=5.2mm 260P SMD REV. AS0A826-H2RB-7 Pin Name MIO-5391 User Manual...
  • Page 65 Description PHONE JACK RJ45 28P DIP RTB-19GB9J1A Pin Name LAN1_MDI0+ LAN1_MDI0- LAN1_MDI1+ LAN1_MDI1- LAN1CONN LAN1_GND LAN1_MDI2+ LAN1_MDI2- LAN1_MDI3+ LAN1_MDI3- LAN1_ACT# +3.3V_LAN1 LAN1_LINK100# LAN1_LINK1000# LAN2_MDI0+ LAN2_MDI0- LAN2_MDI1+ LAN2_MDI1- LAN2CONN LAN2_GND LAN2_MDI2+ LAN2_MDI2- LAN2_MDI3+ LAN2_MDI3- LAN2_ACT# +3.3V_LAN2 LAN2_LINK100# LAN2_LINK1000# MIO-5391 User Manual...
  • Page 66 MIC1L Matching Cable: 1703100152 Table A.17: CN21 External USB3.0 Part Number 1654011725-01 Footprint USB_9x2P_WDU3R-18F3B4PBUW3 Description Double USB 3.0 CONN. 18P 90D(F) DIP WDU3R-18F6B4 Pin Name USB1_D- USB1_D+ USB1_SSRX- USB1_SSRX+ USB1_SSTX- USB1_SSTX+ USB2_D- USB2_D+ USB2_SSRX- USB2_SSRX+ USB2_SSTX- USB2_SSTX+ MIO-5391 User Manual...
  • Page 67 Table A.18: CN22 External USB3.0 Part Number 1654011725-01 Footprint USB_9x2P_WDU3R-18F3B4PBUW3 Description Double USB 3.0 CONN. 18P 90D(F) DIP WDU3R-18F6B4 Pin Name USB3_D- USB3_D+ USB3_SSRX- USB3_SSRX+ USB3_SSTX- USB3_SSTX+ USB4_D- USB4_D+ USB4_SSRX- USB4_SSRX+ USB4_SSTX- USB4_SSTX+ MIO-5391 User Manual...
  • Page 68 Footprint HD_5x2P_79_N10 Description PIN HEADER 2x5P 2.0mm 180D(M) SMD 21N22050 Pin Name USB7_D- USB8_D- USB7_D+ USB8_D+ Table A.20: CN24 SATA Power Part Number 1655001154 Footprint WF_4P_98_BOX_R1_D Description WAFER BOX 4P 2.50mm 180D(M) DIP 24W1170-04S10-01 Pin Name +12V MIO-5391 User Manual...
  • Page 69 Table A.21: CN25 SATA Part Number 1654013615-01 Footprint SATA_7P_WATF-07DBN6SB1U Description SATA 7P/1.27mm/LCP/F/VA/G15u/S/BK/H8.41/W Post Pin Name Table A.22: CN27 SATA Part Number 1654013615-01 Footprint sata_7p_watf-07dbn6sb1u Description SATA 7P/1.27mm/LCP/F/VA/G15u/S/BK/H8.41/W Post Pin Name MIO-5391 User Manual...
  • Page 70 PCIE_TX4- PCIE_CLK11+ LOUTL PCIE_CLK11- LOUTR GND_AGND SMB_STB_CLK SMB_STB_DAT PCIE_WAKE# RESET# SLP_S3# LPC_AD0 DDP_HPD LPC_AD1 LPC_AD2 DDP_AUX+/DDC_CLK LPC_AD3 DDP_AUX-/DDC_DAT LPC_SERIRQ DDP3_TX0+ LPC_FRAME# DDP3_TX0- USB5_D+ DDP3_TX1+ USB5_D- DDP3_TX1- USB5_SSTX+ DDP3_TX2+ USB5_SSTX- DDP3_TX2- USB5_SSRX+ DDP3_TX3+ USB5_SSRX- DDP3_TX3- USB5_OC# +12VSB +12VSB MIO-5391 User Manual...
  • Page 71 Table A.23: CN30 MIOe +5VSB +5VSB +5VSB +5VSB MIO-5391 User Manual...
  • Page 72 Part Number 1655904020 Footprint FPC4V-125M Description WAFER 4P 1.25mm 180D(M) SMD 85205-04001 Pin Name SMB_DAT SMB_CLK Table A.25: CN32 Smart FAN Part Number 1655004347 Footprint WF_4P_100_D_744-81-04TW30 Description WAFER 2.54 1*4P 180D(M) DIP 744-81-04TW30 Pin Name +12V SPEED MIO-5391 User Manual...
  • Page 73 +3.3V(Def) or +5V or +12V +3.3V(Def) or +5V or +12V +3.3V(Def) or +5V or +12V +3.3V (Def)or +5V or +12V LVDS0_D0- LVDS1_D0- LVDS0_D0+ LVDS1_D0+ LVDS0_D1- LVDS1_D1- LVDS0_D1+ LVDS1_D1+ LVDS0_D2- LVDS1_D2- LVDS0_D2+ LVDS1_D2+ LVDS0_CLK- LVDS1_CLK- LVDS0_CLK+ LVDS1_CLK+ LVDS0_D3- LVDS1_D3- LVDS0_D3+ LVDS1_D3+ VCON MIO-5391 User Manual...
  • Page 74 Table A.28: CN36 HDMI Part Number 1654013546-01 Footprint HDMI_38P_QJ11191-DEB1-4F Description HDMI 2x19P/1.5mm/F/PA9T/RA/GFL/D/BK/H18.05/W SC Pin Name Pin Name HDMI_TX2+ HDMI_TX2- HDMI_TX1+ HDMI_TX1– HDMI_TX0+ HDMI_TX0– HDMI_CLK+ GND` HDMI_CLK– +5V Power Hot Plug Detect MIO-5391 User Manual...
  • Page 75 NGFF 75P/0.5mm/(F)/LCP/RA/GFL/S/BK/H8.5mm/E-key Pin Name Pin Name +3.3VSB USB6_D+ +3.3VSB USB6_D- NC/SDIO_CLK NC/SDIO_CMD NC/SDIO_DATA0 NC/SDIO_DATA1 NC/SDIO_DATA2 NC/SDIO_DATA3 NC/SDIO_WAKE# NC/SDIO_RESET# PCIE_TX7+ PCIE_TX7- PCIE_RX7+ PCIE_RX7- PCIE_CLK_M2E+ PCIE_CLK_M2E- PCIE_SUSCLK PCIE_PERESET# PCIE_CLKREQ2# BT_DISABLE# PCIE_WAKE# WIFI_DISABLE# PCIE_TX8+ PCIE_TX8- PCIE_RX8+ PCIE_RX8- NC/REFCLKp1 +3.3VSB NC/REFCLKn1 +3.3VSB MIO-5391 User Manual...
  • Page 76 Pin Name DCD4# DSR4# RXD4 RTS4# TXD4 CTS4# DTR4# RI4# Table A.31: CN45 Front Panel Part Number 1653004099 Footprint HD_5x2P_79_23N685B-10M10 Description BOX HEADER 5x2P 2.00mm 180D(M) SMD 23N685B-10M10 Pin Name POWER_BUTTON RESET CASE_OPEN +3.3V SATA_LED# BUZZER+ BUZZER- MIO-5391 User Manual...
  • Page 77 MINI PCI E 52P 6.8mm 90D SMD AS0B226-S68Q-7H Pin Name Pin Name PCIE_WAKE# +3.3VSB +1.5V PCIE_MINI_CLK5_CLKREQ# +VUIM_PWR UIM_DATA PCIE_MINI_CLK5- UIM_CLK PCIE_MINI_CLK5+ UIM_RESET +VUIM_VPP WIFI_DISABLE# PERST# mSTAT_mPCIE_RX- +3.3VSB mSTAT_mPCIE_RX+ +1.5V SMB_CLK mSTAT_mPCIE_TX- SMB_DAT mSTAT_mPCIE_TX+ USB9_ D- USB9_ D+ +3.3VSB +3.3VSB mPCIE(GND)/mSATA(NC) +1.5V +3.3VSB MIO-5391 User Manual...
  • Page 78 Table A.33: CN48 GPIO Part Number 1653004099 Footprint HD_5x2P_79_23N685B-10M10 Description BOX HEADER 5x2P 2.00mm 180D(M) SMD 23N685B-10M10 Pin Name DCD2# DSR2# RXD2 RTS2# TXD2 CTS2# DTR2# RI2# MIO-5391 User Manual...
  • Page 79 Nano SIM Card 6P/1.27/(F)/LCP/RA/GFL/S/BK/H1.37 Pin Name +VUIM_PWR UIM_RESET UIM_CLK UIM_VPP UIM_DATA Table A.35: CN50 GPIO Part Number 1653004099 Footprint HD_5x2P_79_23N685B-10M10 Description BOX HEADER 5x2P 2.00mm 180D(M) SMD 23N685B-10M10 Pin Name DCD1# DSR1# RXD1 RTS1# TXD1 CTS1# DTR1# RI1# MIO-5391 User Manual...
  • Page 80 MIO-5391 User Manual...
  • Page 81 Appendix System Assignments This appendix contains informa- tion of a detailed nature. Sections include:  System I/O Ports  DMA Channel Assignments  1st MB Memory Map  Interrupt Assignments...
  • Page 82 3F8h-3FFh Communications Port (COM1) 4D0h-4D1h Interrupt Controller 164Eh-164Fh Motherboard resources 1800h-18FFh Motherboard resources CF9h-CF9h Reset Generator DMA Channel assignments Table B.2: DMA Channel assignments Channel Function Available Available Available Available Direct memory access controller Available Available Available MIO-5391 User Manual...
  • Page 83 Communications Port (COM2) IRQ4 Communications Port (COM1) IRQ5 EC Watch DOG IRQ6 Available IRQ7 Available IRQ8 System CMOS/real time clock IRQ9 Microsoft ACPI-Compliant System IRQ10 Available IRQ11 SATA controller IRQ12 Available IRQ13 Numeric data processor IRQ14 Reserved IRQ15 Reserved MIO-5391 User Manual...
  • Page 84 No part of this publication may be reproduced in any form or by any means, electronic, photocopying, recording or otherwise, without prior written permis- sion of the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2019...
