- Page 1 SM08 Advanced Composite Video Interface: aCVi Receiver module User Manual Revision 0.1 March 2020 SM08 User Manual Revision 0.1 Page 1 of 22...
-
Page 2: Revision History
Revision History Date Revisions Version 06-03-2020 First Draft. SM08 User Manual Revision 0.1 Page 2 of 22... -
Page 3: Table Of Contents
Figure 3 Left: Original full resolution image. Right: Image after Bayer demosaicing....... 6 Figure 4 aCVi® Modules..........................6 Figure 5 SM08 Interconnections....................... 7 Figure 6 SM08 Schematics - Sheet 1....................... 10 Figure 7 SM08 Schematics - Sheet 2....................... 11 Figure 8 SM08 Schematics - Sheet 3....................... 12 Figure 9 SM08 Schematics - Sheet 4. -
Page 4: Introduction
SM08 is a receiver module compatible with the aCVi® Advanced Composite Video Interface format. SM08 accepts analogue aCVi® encoded video from both twisted pair and low-cost coaxial cable which it converts to HD-SDI format video. SM08... -
Page 5: Acvi Overview
The following is a brief overview of the aCVi® revision 2 interface (abbreviated to aCVi® in this document). aCVi® is a proprietary format, developed by SingMai Electronics, to transmit high definition video over long distances of coaxial or twisted pair cable. aCVi® is an update to the previous version, specifically designed to interface directly to image sensors, although it may also be used to transmit conventional video sources. -
Page 6: Figure 3 Left: Original Full Resolution Image. Right: Image After Bayer Demosaicing
SDI or DVI video sources (e.g. a video camera) and simultaneously drives both coaxial and twisted-pair cable. The receiver module is the SM08. This module accepts either twisted-pair or coaxial cable and converts the aCVi® video to an HD-SDI output for a TV monitor or video recorder. -
Page 7: Connecting Up The Module
2 ‘VIDEO-‘ (inverted) signal. If the aCVi® input is valid and can be locked to, the yellow ‘Lock’ LED will light – the SM08 automatically detects the input video standard. Once the aCVi® decoder has locked and is decoding the yellow ‘SDI lock LED’... -
Page 8: Circuit Description
4. Circuit description Figures 6-14 show the schematics for the SM08. Below is a brief technical description of the module. Sheet 1. J3 is the 5VDC power input connector to the SM08 module. The 5VDC is protected from over-voltage and reverse polarity inputs by D1, D2 and resettable fuse, F1. The input is then filtered by L1 and C2 to provide the ‘clean’... - Page 9 The scrambled signal is then multiplexed into 5 data streams at 148.5MHz which are driven as LVDS outputs, together with an LVDS clock, to the HD-SDI serialiser IC, U18, which converts these five data signals into one 1.485GHz, HD-SDI compatible, output (J9). SM08 User Manual Revision 0.1 Page 9 of 22...
-
Page 10: Figure 6 Sm08 Schematics - Sheet 1
Figure 6 SM08 Schematics - Sheet 1. SM08 User Manual Revision 0.1 Page 10 of 22... -
Page 11: Figure 7 Sm08 Schematics - Sheet 2
Figure 7 SM08 Schematics - Sheet 2. SM08 User Manual Revision 0.1 Page 11 of 22... -
Page 12: Figure 8 Sm08 Schematics - Sheet 3
Figure 8 SM08 Schematics - Sheet 3. SM08 User Manual Revision 0.1 Page 12 of 22... -
Page 13: Figure 9 Sm08 Schematics - Sheet 4
Figure 9 SM08 Schematics - Sheet 4. SM08 User Manual Revision 0.1 Page 13 of 22... -
Page 14: Figure 10 Sm08 Schematics - Sheet 5
Figure 10 SM08 Schematics - Sheet 5. SM08 User Manual Revision 0.1 Page 14 of 22... -
Page 15: Figure 11 Sm08 Schematics - Sheet 6
Figure 11 SM08 Schematics - Sheet 6. SM08 User Manual Revision 0.1 Page 15 of 22... -
Page 16: Figure 12 Sm08 Schematics - Sheet 7
Figure 12 SM08 Schematics - Sheet 7. SM08 User Manual Revision 0.1 Page 16 of 22... -
Page 17: Figure 13 Sm08 Schematics - Sheet 8
Figure 13 SM08 Schematics - Sheet 8. SM08 User Manual Revision 0.1 Page 17 of 22... -
Page 18: Figure 14 Sm08 Schematics - Sheet 9
Figure 14 SM08 Schematics - Sheet 9. SM08 User Manual Revision 0.1 Page 18 of 22... -
Page 19: Specification
14MHz ± 1dB. >-40dB @ 17.6MHz. Transmission distance: >300m of RG-59 coaxial cable. >500m RG-59 cable with reduced luma bandwidth. Latency: <100µs (transmitter HD-SDI input to receiver HD-SDI output). Operating temperature: -10° to +45°degC. SM08 User Manual Revision 0.1 Page 19 of 22... -
Page 20: Appendix A: Power Supply Specification
The AC-DC converter supplied with the SM06 is a model TE10A0503F01 from SL Power Electronics. It accepts all AC inputs from 90-264VAC and provides a 5V, 2A DC output for the SM06. The detailed specification is shown below. Figure 15 Power supply specification - page 1. SM08 User Manual Revision 0.1 Page 20 of 22... -
Page 21: Figure 16 Power Supply Specification
Figure 16 Power supply specification - page 2. SM08 User Manual Revision 0.1 Page 21 of 22... -
Page 22: Figure 17 Power Supply Specification
Figure 17 Power supply specification - page 3. SM08 User Manual Revision 0.1 Page 22 of 22...
