External Safety Air Bleed Kit Instructions
Effective December 2006, the External Safety Air Bleed Kit (ESABK) comes with every UltraPure
Automatic Water Cleaner
kit is designed to take air from the top of the filter and send it downstream (up to 15) past any and all
equipment. The supplied tee screws into the pressure gauge port. In some cases, it is necessary to install
this tee into the manual air relief port of opening. Be sure all air is venting from the filter as the pump
runs. The internal bleed in the filter acts as a backup to the external kit. Installation of the ESABK is
necessary when: the filter is old and does not have an internal air bleed; when there is a solar system
on the pool; when there is a pressure side cleaner; when using a booster pump; or on newer filters which
will not evacuate the air.
See parts package included with your UltraPure
OPERATION
To achieve optimal performance from the UltraPure
clean as possible to start with.
Back wash or clean the filters before starting the UltraPure
Test the pool water and adjust as stated in the chart below.
e T
Free Available Chlorine (FAC)
Total Chlorine (TC)
Bromine
pH
Total Alkalinity (TA)
Calcium Hardness (CH)
Total Dissolved Solids (TDS)
The free chlorine or bromine residual should be maintained at all times. Outdoor pools on chlorine
require a stabilizer. Pool may require a shock treatment after heavy usage, heavy rains or wind storms.
Follow your dealer's recommendations.
When the pool circulation system starts, the sight glass located on the front of the unit will glow blue
to let you know instantly that the system is working.
Check the returns. Bubbles in the pool means ozone is getting into the water.
Your UltraPure ™ Automatic Water Cleaner
indoors during cold weather or when not in use. Should foreign matter enter the bulb chamber, the bulb
may be carefully cleaned using methanol alcohol. Always be sure to disconnect the power before remov-
ing the end plates. UV rays can temporarily 'Blurr' your vision.
6
Pool Owner's Manual and Installation Instructions
UltraPureManual12pg34072.indd 8 UltraPureManual12pg34072.indd 8
™ . The ESABK is not needed or included with the above ground units. This
t s
™ is virtually maintenance free. Your unit should be stored
™ Automatic Water Cleaner
™
Automatic Water Cleaner
™ Automatic Water Cleaner
d I e l a R a n g
1.0 ppm (minimum)
Up to 0.5 ppm above the FAC reading
2.0 ppm
7.2 - 7.8
80 – 120 ppm
200 – 300 ppm
300 – 1200 ppm
™
™.
™
, the pool must be as
™ .
e
