radio bus
Radio hand-held transmitter comfort
Radio hand-held transmitter comfort
Order-No. : 2766
Operation- and
Assembly Instructions
1 Safety instructions
Electrical equipment may only be installed and fitted by electrically skilled persons.
Failure to observe the instructions may cause damage to the device and result in fire and
other hazards.
Risk of explosion! Do not recharge batteries.
Risk of explosion! Do not throw batteries into fire.
These instructions are an integral part of the product, and must remain with the end
customer.
2 Device components
(1) Hand transmitter
(2) All On button
(3) All Off button
(4) Group buttons with LED
(5) Channel buttons
(6) Light scene buttons
(7) Master dimming button
3 Function
System information
By statute, the transmitting power, the reception characteristics and the antenna cannot be
changed.
The device may be operated in all EU and EFTA countries.
The declaration of conformity can be viewed on our website.
The range of a radio system from the transmitter to the receiver depends on various
circumstances.
82526111
97-09495-000
Figure 1
Seite 1/6
12.09.2011
Advertisement
Table of Contents
Related Manuals for Berker 2766
Summary of Contents for Berker 2766
- Page 1 Radio hand-held transmitter comfort Radio hand-held transmitter comfort Order-No. : 2766 Operation- and Assembly Instructions 1 Safety instructions Electrical equipment may only be installed and fitted by electrically skilled persons. Failure to observe the instructions may cause damage to the device and result in fire and other hazards.
- Page 2 radio bus Radio hand-held transmitter comfort The range of the system can be optimised by selecting the optimal installation location, taking into account the structural circumstances. Figure 2: Reduced range due to structural obstacles Example of penetration of various materials: Material Penetration Wood, Plaster, Plasterboard...
- Page 3 radio bus Radio hand-held transmitter comfort Permanent changing of the group Press group button for longer than 4 seconds. The LED of the group flashes for approx. 4 seconds. Desired group is active continuously. Transmitting radio telegrams Each channel button can be operated on the left /\ or right \/. The radio transmitter has been taught (see Commissioning chapter).
- Page 4 radio bus Radio hand-held transmitter comfort Set the required lighting situation. Press the desired light scene button for longer than 3 seconds. First the old light scene is called up; do not release the button during this. After about 3 seconds the new light scene is saved and activated.
- Page 5 radio bus Radio hand-held transmitter comfort WARNING! Risk of chemical burns. Batteries can burst and leak. Exchange all batteries in a set at the same time. Replace batteries only with an identical or equivalent type. Insert batteries (9). Note the correct polarity. Close battery compartment.
- Page 6 Our products are under guarantee within the scope of the statutory provisions. If you have a warranty claim, please contact the point of sale or ship the device postage free with a description of the fault to the appropriate regional representative. Berker GmbH & Co. KG Klagebach 38 58579 Schalksmühle/Germany...
