- Page 1 AcePro-CE88-1 HDMI 2.0 HDBaseT Extender with RS-232 & IR/PoC Quick Installation Guide Transmitter Receiver www.avlab.com.tw support@avlab.com.tw Made in Taiwan AP4-0097B...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ........................ 2 FEATURES ........................2 PACKAGE CONTENTS ...................... 3 SPECIFICATIONS ......................4 PANEL DESCRIPTIONS ....................5 CONNECTION DIAGRAM ....................6 IR PASS-THROUGH ......................7 HDMI PIN DEFINITION ...................... 8 HARDWARE INSTALLATION..................... 8 NOTICE ..........................9 WARRANTY ........................10... -
Page 3: Introduction
The AcePro-CE88-1 includes two units: transmitting unit AcePro-CE88-1-TX and receiving unit AcePro-CE88-1-RX. The transmitting unit is used to capture the input HDMI / DVI signals with IR control packets and carry the signals via one cost effective Cat.5/5e/6 cable. The receiving unit is responsible for equalizing the transmitted HDMI signal and reconstructing IR and serial control signals. -
Page 4: Package Contents
The length depends on the characteristics and quality of the cables. Higher resolutions and longer transmission distances require low skew cables (<25ns/100m) for best performance. Unshielded CAT6 with metal RJ45 connectors is recommended. PACKAGE CONTENTS 1x HDMI 2.0 HDBaseT Extender (AcePro-CE88-1 [TX & RX]) 1x IR blaster 1x IR receiver ... -
Page 5: Specifications
SPECIFICATIONS Model Name AcePro-CE88-1 Technical Role of usage Transmitter [TX] Receiver [RX] HDMI compliance HDMI 2.0a HDCP compliance HDCP 2.2 & 1.4 Video bandwidth Single-link 594MHz [18Gbps]* Video support HDR 4K2K@60 (4:2:0 10bits) / 4K2K@60 (4:4:4 8bits) HDMI over UTP... -
Page 6: Panel Descriptions
7. Power LED: Power indicator LED 8. Link LED: Link indicator LED 9. RJ45: Plug in a Cat-5/5e/6 cable that needs to be linked to the receiving unit AcePro-CE88-1-RX Receiving unit ► AcePro-CE88-1-RX 1. Slide Switch: for F/W update ([Left] Normal Mode; [Right] F/W update Mode) -
Page 7: Connection Diagram
CONNECTION DIAGRAM... -
Page 8: Ir Pass-Through
IR PASS-THROUGH [IR Extenders] IR Blaster IR Receiver [IR Sockets] IR BLASTER: plug in the IR blaster to emit all IR command signals received from the IR receiver from the other end to control the devices corresponding to the IR signals. IR RECEIVER: plug in the IR receiver to receive all IR command signals from the IR remote controls of the corresponding devices. -
Page 9: Hdmi Pin Definition
Connect IR Blaster/Receiver to both TX and RX units. Connect a Cat-5/5e/6 cable between the transmitting and receiving units. Make sure this Cat-5/5e/6 cable is tightly connected. Plug in 12V DC power supply unit to the power jack of the receiving unit AcePro-CE88-1-RX or the transmitting unit AcePro-CE88-1-TX. -
Page 10: Notice
NOTICE 1. All HDMI over CAT5 transmission distances are measured using Belden 1583A CAT5e 125MHz UTP cable and ASTRODESIGN Video Signal Generator VG-859C & VG-870B. 2. Incorrect placement of IR Blaster and Receiver may result in the failure of the IR extenders. Please check carefully before plugging in the IR extender to the respective IR sockets. -
Page 11: Warranty
IR/PoC free from defects in the material and workmanship for 1 year from the date of purchase from the AceProAV or an authorized dealer. Should this product fail to be in good working order within 1 year warranty period, The AceProAV, at its option, repair or replace the unit, provided that the unit has not been subjected to accident, disaster, abuse or any unauthorized modifications including static discharge and power surge. - Page 12 Feb, 2020 Ver. A © Copyright by AceProAV, LLC. All rights reserved.
