Hyndsight Vision Systems CRUZ Quick Manual

Fully charge both devices before using.
To Charge Your Hyndsight System
Connect the USB cable to the Wall Charger.
Insert the straight jack into the Camera/Monitor.
Plug in the Wall Charger.
Red light appears when charging. Red light turns off when charge is complete (3-4 hours).
Hyndsight Systems are equipped with multiple functions depending upon if Multi-Camera mode is Disabled (only one camera can be used) or Enabled
(more than one camera can be used).
Remove the protective screen cover from the Monitor before using. HVS recommends pairing Cameras before mounting them to desired surfaces. Using
your best judgment, attach Camera and Monitor Antennas either before or after mounting Devices to desired surfaces. Note: Unpair, Select, and Scan
settings are disabled in Single Camera mode.
To Power On* Your Hyndsight System
Hold Monitor Power
on.
Hold Camera Power
illuminate to show Camera is on.
*Always power up Monitor before Camera to help sync automatically. If Camera and Monitor do not sync automatically, follow the steps below:
Press the Menu
Scroll to Pair using
Select Pair by hitting the Enter
Monitor screen will go white and the Green Indicator Light will flash.
While Monitor's Green Indicator Light is flashing, press the Pair
After Single Camera is paired, the viewing perspective may be changed between Mirror-image or Forward-facing views. Single Camera mode defaults
to a Mirrored view. Mirrored view is ideal when backing up to provide you with an accurate view of the locations of objects behind you.

Forward-facing View

Displays a view consistent with what you would see if you were viewing an object head-on.

To Switch to Forward-facing View

THE QUICK GUIDE TO HYNDSIGHT CRUZ
button for 3 seconds until the orange Hyndsight screen appears. Green Indicator Light will light up to show Monitor is
button for 2-3 seconds. An image will appear on the Monitor after you release the Power button. Indicator Light will
button.
or .
button.

CHARGING

SINGLE CAMERA SET-UP

button on Camera and an image will appear on Monitor.
