To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the
installation instructions.
•
Use the screws and wall mounts that meet the following specifications. Any damages or injuries by
misuse or using an improper accessories are not covered by the warranty.
Note:
1. The pictures are only for reference.
2. For the TV sets with terminals towards the wall, in order to leave enough space to use the terminals, a rubber
cushion is needed together with each screw to fix the wall mount. It is a sma
diameter is 8mm, external diameter is 18mm and height is �30mm.
Precautions For Using Remote Control
•
VOICE ( •r) button can be used only when the R/C is connected to your TV via bluetooth
•
To pair bluetooth remote control with TV, please follow the steps shown in
E-Manual
Google Assistant
>
•
Use the remote control by pointing it towards the remote sensor. The items between the remote
control and the remote sensor will interfere the normal operation.
Do not make remote control vibrate violently. Also, do not splash liquid on the remote control, also do
•
not put the remote control in high humidity place.
Do not place remote control under direct sunlight which will cause deformation of the unit by heat.
•
When the remote sensor is under direct sunlight or strong lighting, the remote control will not work. If
•
so please change the lighting or TV's position, or operate the remote control closer to the remote
sensor.
Precautions For Using Battery
Improper usage of the battery will cause leakage. So follow below instructions and use carefully.
1. When the battery's voltage is insufficient which affect the use range, you should replace new
battery. Remove the batteries from the remote control unit if you do not intend to use it for a long
time.
2.
Do not use different types of batteries (for example, Manganese and Alkaline batteries) together.
3.
Do not put the battery into fire, and charge or decompose the battery.
4.
Please dispose batteries abide by relevant environmental protection regulation.
5.
WARNING: The batteries (battery pack or batteries installed) shall not be exposed to excessive
heat such as sunshine, fire or the like.
Model Size
Diameter(mm) "E"
Depth(mm) I Max
Screw
"D"
I Min
Quantity
A•s•c
Using Conditions
>
55"
Top
Down
M6
M6
28
28
22
22
2
2
300·200•300
11
ho II ow pi I la r whose intern a I
