DUAL ZONE OPERATION

1. Power On/Off Button
2. Battery Monitor Display
3. Temp Decrease Buttons
4. Temp Increase Buttons
5. Temp Display
6. Battery Protection Button
7. Battery Protection Display
8. Compressor Speed Button
9. Compressor Speed Display
POWER – OFF AND ON
1. Press power button & fridge will go into
standby mode then switch off after 5
seconds
2 Press the power button & fridge will re-start
with previously selected settings
ECO FUNCTION – SETTING
1. Press the COMPRESSOR SPEED button &
the speed setting will go between ECO &
MAX
CABINET TEMPERATURE – SETTING
The temperature may be set independently
for each zone in the range -20° to +20°C.
The R/H (large) cabinet MUST be set
to equal to or higher than the L/H
(small) section
SETTING THE LEFT ZONE
1. Adjust Temperature by pressing the L BOX
+ button to increase set temp and the
L BOX - button to decrease set temp
2. Temperature display will flash when
selecting temperature & return to solid
display when showing actual internal
temperature
10
4
3
6
8
SETTING THE RIGHT ZONE
1. Adjust Temperature by pressing the
R BOX + button to increase set temp and
the R BOX - button to decrease set temp
2. Temperature display will flash when
selecting temperature & return to solid
display when showing actual internal
temperature
SHUTTING DOWN A SELECTED ZONE
The Dual cooling system will allow either zone
to be shut down independently to the other.
This is perfect for when the total cabinet space
is not required and provides improved power
efficiencies.
1. Press and hold the L BOX - and + buttons
together for 2-3 seconds and the L/H
Cabinet will stop cooling
2. Repeat the same step and the L/H Cabinet
will recommence operation
3. Press and hold the R BOX - and + buttons
together for 2-3 seconds and the R/H
Cabinet will stop cooling
4. Repeat the same step and the R/H Cabinet
will recommence operation
2 5
• Battery Protection •
High Med Low
• Compressor Speed •
Max Eco
9
• Battery Protection •
High Med Low
• Compressor Speed •
Max Eco
1
7
