Quick Install Guide For bwa™ Kit - BP501/601
TOOL YOU WILL NEED
– Phillips screwdriver
STEP 1
STEP 2
STEP 3
1
WARNING!
Please contact an electrician or your local electrical company to
connect the Wi-Fi connector for you. DO NOT OPEN THE SPA
SYSTEM AND ATTEMP TO CONNECT THE WI-FI CONNECTOR
YOURSELF. The high electrical voltage will harm or kill you.
– Use a phillips screwdriver to remove
2
the 2 top screws that hold the system
cover in place.
– Insert the Balboa Wi-Fi Cable into either Panel Jack
J45 or J33.
– Remove 1 screw to open the cable holder.
Previous
Page
Next
Page
1
2
Advertisement
Related Manuals for Balboa bwa BP501
Water System Balboa bwa BP501 Quick Install Manual
(2 pages)
Control Unit Balboa bwa Kit Quick Install Manual
For bp500/600 (2 pages)
Control Unit Balboa bwa BP500 Quick Install Manual
(2 pages)
Summary of Contents for Balboa bwa BP501
Page 1
– Use a phillips screwdriver to remove the 2 top screws that hold the system cover in place. STEP 1 STEP 2 – Insert the Balboa Wi-Fi Cable into either Panel Jack J45 or J33. – Remove 1 screw to open the cable holder. STEP 3...
Page 2
Wi-Fi module away from any metal tub supports. 0917BP501/601 ©2017 Balboa Water Group. Single Source Solution. All rights reserved. 1382 Bell Avenue | Tustin, CA 92780 | p 714.384.0384 | www.balboawater.com Balboa has the right to change technical data without notice.
