- Page 1 Selfnergy M Series User Manual Hybrid Inverter Allis Electric Co., Ltd. 12F. NO.19-11, San-chung Road, Nan Kang District, Taipei, Taiwan, R.O.C. Tel:+886-2-26553456 E-mail:sales@allis.com.tw www.allis.com.tw...
-
Page 2: Table Of Contents
Contents Contents 1 Note on this Manual Scope of Validity Target Group Symbols Used 2 Safety Important Safety Instructions Explanation of Symbols EC Directives 3 Introduction Basic Features Work Sta Dimension Terminals of Inverter 4 Technical Data 4.1 DC input ( apply to version E, I, C ) 4.2 AC output/input ( apply to version E, I, C ) 4.3 Internal Charger ( apply to version E, I, C ) 4.4 Efficiency, Safety and Protection ( apply to version E, I,C ) -
Page 3: Target Group
Contents Notes on this Manual 1 Notes on this Manual Meter Connection LAN Connection 1.1 Scope of Validity This manual is an integral part of Selfnergy M-Hybrid, It describes the assembly, DRM Connection installation, commissioning, maintenance and failure of the product. Please read it WiFi Connection(optional) carefully before operating. -
Page 4: Safety
Safety Safety 2 Safety WARNING ! Do not operate the in verter when the device is running. 2.1 Important Safety Instructions WARNING ! Danger! Risk of electric shock! Danger to life due to high voltages in the inverter! All work must be carried out by qualified electrician. The appliance is not to be used by children or persons with reduced physical sensory or mental capabilities, or lack of Prior to the application, please read this section carefully to ensure correct and... - Page 5 Safety Safety Surge protection devices (SPDs) for PV installation ► ► PE Connection and Leakage Current • The end-use application shall monitor the protective conductor by residual WARNING ! current operated protective device (RCD) with rated fault current Ifn≤240mA Over-voltage protection with surge arresters should be provided which automatically disconnects the device in case of a fault.
-
Page 6: Explanation Of Symbols
Safety Safety 2.2 Explanation of Symbols The inverter can not be disposed together with the household waste. This section gives an explanation of all the symbols shown on the inverter and Disposal information can be found in the enclosed documentation. on the type label. -
Page 7: Introduction
Introduction Introduction 3. Introduction I Version applies to the wiring rules that requires Neutral line of alternative supply must NOT be isolated or switched (applies to wiring rules AS/NZS_3000:2012 for Australia and New Zealand). 3.1 Basic features Selfnergy M Hybrid Seires is a high-quality inverter which can convert solar energy to AC energy and store energy into battery. -
Page 8: Dimension
Introduction Introduction 3.2 Work Modes Work modes: Back up mode Selfnergy M Series inverter provides multiple work modes based on Priority:battery>load>grid different requirements. This mode applies the area that has frequent power outages. And this mode ensures the battery will has enough energy to supply when Work modes: Self-use (with PV Power) the grid is off . -
Page 9: Terminals Of Inverter
Introduction Technical Data 4. Technical Data 3.4 Terminals of PV inverter 4.1 DC input ( apply to version E, I, C ) X1-Hybrid-5.0-D Model R3KL1 R4KL1 R5KL1 Max. recommended DC power [W] 4600 5600 6000 Max. DC voltage[V] Norminal DC operating voltage[V] MPPT voltage range [V] 125-550 125-550... -
Page 10: Internal Charger ( Apply To Version E, I, C )
Technical Data Technical Data 4.5 EPS output ( apply to version E, I ) 4.3 Internal Charger ( apply to version E, I, C ) R3KL1 R4KL1 R5KL1 Model Model R3KL1 R4KL1 R5KL1 Battery type Lithium battery EPS rated power[VA] 3680 4600 5000... -
Page 11: Installation
Smart Plug (optional) The packing list shown as below. 5.3 Mounting Installation Precaution Selfnergy M Series inverter is designed for outdoor installation (IP 65). Make sure the installation site meets the following conditions: Not in direct sunlight. Not in areas where highly flammable materials are stored. - Page 12 Installation Installation Ø Space Requirement 375.0 mm 300mm Table Available Space Size Position Min.size 300mm 300mm Left 300mm Right 300mm 300mm Bottom 300mm Front 300mm Step 1 300mm Ø Mounting Steps Tools required for installation. Installation tools : crimping pliers for binding post and RJ 45, screwdriver, Step 2 manual wrench and Step 1: Screw the wall bracket on the wall...
-
Page 13: Electrical Connection
Electrical Connection Electrical Connection 6. Electrical Connection Connection Steps: Step1. Checking PV module. 1.1 Use multimeter to measure module array voltage. 1.2 Check the PV+ and PV- from the PV string combiner box correctly. 6. PV connection 1.3 Please make sure the impedance bewteen the positive pole and negative pole of PV to earth should be MΩ... -
Page 14: Grid Connection
Electrical Connection Electrical Connection 6.2 Grid Connection Step2. Selfnergy M Hybrid series inverter are designed for single phase grid. Voltage is 220/230/240V, frequency is 50/60Hz. Other technical requests should comply with the requirement of the local public grid. Table 4 Cable and Micro-breaker recommended Model R3KL1 R4KL1... -
Page 15: Eps Connection( Apply To I Version And E Version)
E Version Manual Required for Changeover Switch Selfnergy M series inverter has On and Off grid function, the inverter will deliver E Version wired by manufactor output power through AC port when the grid is on, and it will deliver output... - Page 16 Electrical Connection Electrical Connection Ø Ø Connection Steps: Requirements for EPS load Step1.Make EPS wires. 3.1 Choose the appropriate wire(cable size: refer to picture below). WARNING ! 3.2 Reserve about 60mm of conductor material sectional area. Make sure the EPS load power rating is within EPS output rating, 3.3 Remove 12mm of insulation from the end of wire.
-
Page 17: Battery Connection
Electrical Connection Electrical Connection 6.4 Battery Connection Note！ The battery communication can only work when the battery BMS is compatible with the inverter. Charging & discharging system of Selfnergy M Hybrid series inverter is designed for high-voltage lithium battery. Before choosing battery, please note the maximum voltage of battery can not Ø... -
Page 18: Meter Connection
Electrical Connection Electrical Connection Ø Meter Connection Steps: 6.5 Meter Connection Please refer to BMS connection steps (page32) for Meter connection. Please kindly Meter is used for monitoring the power usage for entire house, at the meantime, noted the PIN definition and port position will be slightly different. inverter will also need the data from Meter to achieve the Export Control Function. -
Page 19: Lan Connection
Electrical Connection Electrical Connection 6.6 LAN Connection 6.7 DRM Connection LAN communication is the standard communication interface. It can transmit the DRM is provided to support several demand response modes by emitting control data between the router and inverter via the local network. signals as below. -
Page 20: Wifi Connection(Optional)
Electrical Connection Electrical Connection 6.8 WiFi Connection(optional) 6.9 GPRS Connection(optional) Inverter provides a WiFi port which can collect data from inverter and Revo Hybrid inverter provides a GPRS( radio frequency) interface which control the transmit it to monitoring-website via a Pocket WiFi. switch time of a designated load via an exteral Smart Plug (purchase the product (Purchase the product from supplier if needed) from supplier if needed.) so that the load mostly consumes PV energy and incurs... -
Page 21: Inverter Manipulation
Electrical Connection Electrical Connection Ø 6.10 Inverter Manipulation Check the inverter: Step1. Check the status of indicators and LCD screen. The left indicator should be blue and the indicator screen should display the main interface. Ø Start inverter after checking all below steps: Ensure the inverter fixed well on the wall. -
Page 22: Setting
Setting Setting 7. Setting 7 .2 Instructions for LED Indicator HYBRYD ALARM FAULT （ （ （ （ Green） （ （ （ （ Green） (Yellow) (Red) 7.1 Control Panel Initialization Stand-by Hybrid power connection Off-network Bypass of mains flash Fault 7.3 Instructions for the use of three modes （1) Before selecting the mode, you can set it up ac cording to the local power grid, PV input mode and battery type. - Page 23 Setting Setting input mode： (2) Select the corresponding mode based on actual situation Self-generation and self-consumption（system default mode） Enter password Press ENTER button Setting 6 PV input type 1System setting Press ENTER button Enter password Press ENTER button Setting 1Working mode 1System setting Press ENTER button Press ENTER button...
-
Page 24: Lcd Operation
LCD Operation LCD Operation 8 LCD Operation 8.1.5 BMS parameters Interface 8.1.1PV1 input display interface Interface BATTERY PRMETER Battery type：(lead acid, lithium battery) TYPE： LEAD-ACID PV1 INPUT Battery temperature TEMP： ℃ 0 .0 PV1 input real-time voltage VOLT： 33.8V Percentage of battery surplus capacity SOC：... - Page 25 LCD Operation LCD Operation 8.1.9 Load 8.1.13 Status information Interface Interface Description Sy stem information:Power-up mode,standby mode, LOAD hybrid grid-connection,off-grid operation,mains Emergency load (BACKUP) voltage STATE VOLT: 0.00V charging mode, PV charging mode,bypass mode, Emergency load (BACKUP) current SYS： ERROR CURR: 0.00A fault mode, DSP programming, ARM programming...
-
Page 26: Setting
LCD Operation Setting Press ESC button to enter user setting 8.2 Setting 8.1.16 User setting Interface Description Interface Description This interface is used for various information --SETUP-- Press ESC on the Main Display Interface to enter inquiry options. → 1：SYS SETTING --USER-- Press UP/DOWN button to move the the user interface... - Page 27 Setting Setting ① Working mode ③ Program controlled enable Interface Description Interface Description This interface is used to opt for the working mode. -- W O R K E M O D E -- 1:SELF COMSUME -- RCur ENABLE -- back-flow-prevention function.
- Page 28 Setting Setting ⑦ Program controlled enable ① Battery type Interface Description Interface Description This interface is used to select battery type. The power switch of the machine can be realized --REMOTE CTRL-- Press UP/DOWN button to move corresponding --BAT TYPE-- through remote control.
- Page 29 Setting Setting b a tte r y p a rame t e r Lead-acid ④ Charge voltage Interface Description Interface Description This interface is used to select other Li Press UP/DOWN button to increase or battery parameter. --LEAD-ACID -- decrease the input figure; Press UP/DOWN button to move corresponding →1:CHARG-VOLT --CHARGE VOLT--...
- Page 30 Setting Setting ⑦ Battery capacity ① Reactive mode Interface Description Interface Description Press UP/DOWN button to move --BAT CAP-- This value is the capacity of lead-acid corresponding options; INPUT： 0100 batteries with a range of 50~1000; Press Enter to confirm the input and enter UNIT：...
- Page 31 Setting Setting ⑤ High grid voltage ② Grid-connected power Interface Description Interface Description Press UP/DOWN button to adjust the input Grid Over Voltage Protection Point -GRID PERCENT- figure; Press UP/DOWN to adjust the input figure; -GRID VOLT HIGH- INPUT： 100% Press ENTER button to confirm or ESC Press Enter to confirm the input and enter INPUT：...
- Page 32 Setting Setting 8.2.5 485 Address 8.2.8 LCD backlight Interface Description Interface Description Press UP/DOWN button to adjust the input Press UP/DOWN button to adjust the input --LIGHT TIME-- figure; --485 ADDRESS-- figure; INPUT：20 Press ENTER button to confirm or ESC INPUT：...
- Page 33 Setting Setting 8.4.11 Password Setting ① Machine model Interface Description Interface Description This interface will be used to change This interface displays machine model of --PASSWORD-- password for entry into the setup interface; --INVERTER-- the inverter; OLD： XXXXX Press UP/DOWN to adjust the input figure; R5KL1 Press ESC button to return to inquiry NEW：...
- Page 34 Statistics Statistics 8.6 Statistics ③ Peak power Interface Description Interface Description This interface is used to select statistics items; --PEAK POWER-- This interface displays power peak in Press UP/DOWN button to move --STAT-- HISTORY： 5000 history and for the day. corresponding options;...
-
Page 35: Fault Diagnosis And Solutions
Statistics Fault diagnosis and solutions ⑥ The month 9. Fault diagnosis and solutions Interface Description This interface displays power generation for the The inverter is easy to maintain. When you encounter the following month（KWH）； --E-MONTH-- problems, please refer to the Solutions below, and contact the local P V p o w e r g e n e r a t i o n ;... - Page 36 Setting Setting (1) Check the input mode setting is correct. (1) Check if the local voltage and frequency is incompliance with the (2) Disconnect the PV input, restart the inverter and wait until it machine specification; PV Input Short functions normally. (2) If voltage and frequency are within the accepted range, then wait 2 (3) Contact customer service if error warning continues.
