Packing List
Item No.
Description
1.
Bottom Shelf
2.
Front Wheels
3.
Rear Swivel Caster wheel
4.
Vertical Support Panel
5.
Centre Shelf
6.
Top Shelf
7.
Side Support Rail
8.
Accessory Bracket
9.
Axle
10.
Bolt, Washer & nut (Set)
11.
Flat Washer, Cotter Key(Set)
12.
Plastic Cap
13.
chain
14.
Arc Support Plate
15.
Handle
Q'ty
1
2
2
1
1
1
2
2
1
42
2
2
2
2
1
Multi-Purpose Welder Cart
Owner's Manual
Specifications
Weight Capacity
Overall Dimensions
Bottle Chain Dimensions
Torch Assembly Bracket
Tank Capacity
45kgs
705Lx410Wx820Hmm
2@800Lx16Wmm
2@100Lx100Wmm
286x257mm
Advertisement
Related Manuals for Linde BOC 400840
Summary of Contents for Linde BOC 400840
- Page 1 Multi-Purpose Welder Cart Owner's Manual Packing List Specifications Item No. Description Q'ty Bottom Shelf Front Wheels Weight Capacity 45kgs Rear Swivel Caster wheel Vertical Support Panel Overall Dimensions 705Lx410Wx820Hmm Centre Shelf Bottle Chain Dimensions 2@800Lx16Wmm Top Shelf Side Support Rail Torch Assembly Bracket 2@100Lx100Wmm Accessory Bracket...
- Page 2 Warning! Do not exceed the Mig Welding Cart maximum capacity of 100lbs. Save This Manual Warning! Weight on all the shelves must be evenly distributed and balanced for safety. It’s a good idea to keep this manual in a safe place as it provides you with assembly instructions, parts list Note: Read and adhere to all of the safety warnings and instructions provided in the instruction manual of the as well as safety information.
