- Page 1 User Manual DME204 4.11.10 001A...
- Page 2 Please read carefully the following instructions before switching the product on: - WARNING! Correct fitting and installation is of the utmost importance. Incorrect fitting and/or installation may result in personal injury or loss. INNES disclaims all liability, of whatever kind, if the product is assembled, fitted and/or installed in an incorrect manner.
- Page 3 Table of Contents Introduction Getting started LEDs Connectors Configuration Web interface Technical specifications Troubleshooting Conformities Contacts...
- Page 4 This device is intended to work with the supplied power supply unit. This power supply unit must be connected to a mains socket conforming to standard NF C 15-100. If the AC power cable is damaged, it must be replaced. It is possible to order a replacement mains unit by sending a request to the email address sales@innes.pro.
- Page 5 Getting started with the device Front face DME204 USB 2.0 connector Infrared/GPIO connector Status Green Led Power supply Red Led Rear face ASI connector Express Card connector RS232 connector USB1 2.0 connector USB2 2.0 connector LAN1 RJ45 connector LAN2 RJ45 connector...
- Page 7 Device start-up step > Step 1 (T0=0s) Step 2 (T~24s) Step 3 (T~45s) Device start-up initialisation Device start-up finalisation Nominal mode This phase duration is depending on some variable values During this step, the device has to play the content. (like NTP), some network access duration or some data When firmware upgrade process occured, in checking (check-disk)
- Page 8 LEDs behaviour LED POWER behaviour (power on device) State Information OK: Power supplied Error : Power supply issue ¹ LED LAN behaviour (power on device) State Information There is no network traffic on the Ethernet connector Blinking The blinking frequency is indicating the data rate on Ethernet connector LED STATUS behaviour depending on device start-up steps •...
- Page 9 ¹ If the problem persists in despite of an appropriate power-supply, contact technical support. ² If the problem persists, it is recommended to find out the media not supported yet by the system and remove it from content. ³ If the problem persists after a partition repairing, contact technical support.
- Page 10 Ethernet RJ-45. 10/100/1000 BaseT. It is recommended to use shielded cables. When two cables are connected, the DME204 device works also like a switch. The user can thanks to the device WebUI, inactivate the multicast mode on the LAN1 connector or the LAN connector.
- Page 11 During boot, the GPIO1 is configured in input during some seconds. And then after the system startup, the GPIO1 is operational. The GPIO has a weak pull-up. It is not recommended to hotplug/unplug the GPIO1 connector, which could damage the device. Principle schematics for several use cases Three wires input configuration for GPIO1: DME204 PERIPHERAL 3.3V 1 (Jack) 3 (Jack)
- Page 12 GPIO1 connector configuration can be done through system preferences edition with device WebUI or with a configuration script. GPIO1 configuration part for this script is described here: // Set the direction : input or output (aDirection == "out") Services.prefs.setBoolPref("innes.app-profile.gpio-input.epld_1.jack35_1.*.authorized", false); Services.prefs.setBoolPref("innes.app-profile.gpio-output.epld_1.jack35_1.*.authorized", true); else if (aDirection == "in") Services.prefs.setBoolPref("innes.app-profile.gpio-input.epld_1.jack35_1.*.authorized", true);...
- Page 13 : allows to load the certificates required to play some specific HTML page or to connect to WebDAV servers with the https scheme Certificates It is highly recommended that your device DME204 is on time. When it is possible, synchronize the time & date with a NTP server. ⚠...
- Page 14 It is recommended to enter a unic for each device used on your locak network. When using several devices DME204 spread on several buildings or on ⚠ Hostname several locations, it is recommended to enter values having a specific key word reminding the building and the location of the device (for exmaple:...
- Page 15 Technical specifications Model Constructor DME204 INNES Processors Intel Z350 1.6 GHz VPU/GPU Intel GMA500 Video decoder MPEG2, H264 1080p Encoder Video H264 Audio Mpeg layer II or AAC Resolution 1280x720 (HD), 1024x768, 1024x576, 720x576 (PAL), 720x480 (NTSC), 352x288 (CIF), 176x144 (QCIF) Peripherals 3x USB 2.0 Host (Low/Full/High Speed)
- Page 16 Error while playing a media: message "This content <media path/file name> is not compatible with this device" Troubleshooting To solve the issue, remove this not supported media from your playout and publish again. ¹ ¹ For further information, read the document gekkota-supported-medias-and-performances.pdf ² For further information, contact support@innes.pro...
- Page 17 Conformities In conformity with the following European directives: LVD 2014/35/EU EMC 2014/30/EU...
- Page 18 Contacts For further information, please contact us at + 33 (0)2 23 20 01 62 or by e-mail: Technical support: support@innes.pro Sales department: sales@innes.pro FAQ and download at : http://www.innes.pro/en/support/ INNES SA 5A rue pierre Joseph Colin 35700 RENNES Tel: +33 (0)2 23 20 01 62 Fax: +33 (0)2 23 20 22 59 http://www.innes.pro/fr...
