CONDENSING RECIRCULATING TANKLESS GAS WATER HEATER
Model : PR199DV
FOR USE IN RESIDENTIAL OR
MANUFACTURED HOME APPLICATIONS.
WARNING
• Do not store or use
gasoline or other
flammable vapors and
liquids in the vicinity
of this or any other
appliance.
PB HEAT, LLC
Owner's Guide
If the information in this manual is not followed exactly, a fire or explosion may result
causing property damage, personal injury or death.
• WHAT TO DO IF YOU SMELL GAS
- Do not try to light any appliance.
- Do not touch any electrical switch; do not use any
phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
- If you cannot reach your gas supplier, call the fire
department.
(GQ-C3260WXQ-FF PB US)
Thank you for purchasing this Pavilion Tankless Gas Water
Heater.
Before using:
• Read this manual completely for operation instructions.
• To be covered by the Pavilion Limited Warranty service, see
the warranty registration information (See page 23), and
then visit the Pavilion web site (https://www.peerlessboilers.
com/).
• Keep this manual because the warranty registration
information is included (See page 23).
Installation must conform with local codes, or in the absence of
local codes, the National Fuel Gas Code, ANSI Z223.1 / NFPA 54
- latest edition and/or the Natural Gas and Propane Installation
Code CSA B149.1 - latest edition.
When applicable, installation must conform with the
Manufactured Home Construction and Safety Standard, Title
24 CFR, Part 3280 or the Canadian Standard CAN/CSA-Z240 MH
Mobile Homes, Series M86.
PB Heat reserves the right to discontinue, or change at any
time, the designs and/or specifications of its products without
notice.
SBB819F-1
Rev. 12/19
• Installation and service
must be performed by
a qualified installer,
service agency or the
gas supplier.
Low NOx Approved by SCAQMD
14 ng/J or 20 ppm
(Natural Gas Only)
Advertisement
Table of Contents
Related Manuals for PB Heat PAVILION PR199DV
Summary of Contents for PB Heat PAVILION PR199DV
- Page 1 Manufactured Home Construction and Safety Standard, Title 24 CFR, Part 3280 or the Canadian Standard CAN/CSA-Z240 MH Mobile Homes, Series M86. PB Heat reserves the right to discontinue, or change at any time, the designs and/or specifications of its products without notice.
-
Page 2: Important Safety Information
Important Safety Information To prevent damage to property and injury to the user, the icons shown below will be used to warn of varying levels of danger. Every indication is critical to the safe operation of the Water Heater and must be understood and observed. Potential dangers from accidents during installation and use are divided into the following four categories. - Page 3 WARNING To prevent burns or scalding, turn off the button and wait until the appliance cools A. This Water Heater does not have a pilot. before performing maintenance. It is equipped with an ignition device that automatically lights the burner. Do not try Do not place the exhaust vent terminal in an to light the burner by hand.
- Page 4 WARNING [When supplying combustion air from the indoors] Be sure the gas/power supplied matches Check the air supply opening for dust or “Type of Gas” and “Electrical Rating” on the obstructions. rating plate. To prevent inury or death, do not allow small children to bathe or play in the bathroom unsupervised.
- Page 5 NOTICE Do not disassemble the Remote Controller. Do not drink water that has been inside the Do not use chlorine-based, acidic, alkaline appliance for an extended period of time. Do detergents, organic solvents such as benzine not drink the first use of hot water from the and thinner, or Melamin Sponge to clean the appliance in the morning.
-
Page 6: Table Of Contents
Contents Important Safety Information ....2 Contents ..........6 General Parts ........7 Water Heater ........7 Remote Controller ........ 8 Features of the Auto-Recirculation Mode ........... 9 Initial Operation ........9 Using the Water Heater ......10 Setting Hot Water Temperature ....10 Customizable Settings......11 Limiting the Maximum Output Temperature .......... -
Page 7: General Parts
General Parts Water Heater Indoor Installation Outdoor Installation Outdoor Vent Cap Flex Vent 2 in. Conversion Kit 1. Intake Pipe 2. Exhaust Pipe 3. Front Cover 4. Water Drain Valve (with Water Filter) (See page 16) 4-1: Inside the cold water inlet 4-2: Inside the hot water return 5. -
Page 8: Remote Controller
Remote Controller • What is actually displayed depends on how the Water Heater is set. • Before use, remove the protective sheet from the Remote Controller surface. 1. POWER Button / Indicator 5. BURNER ON Indicator For turning the Water Heater ON/OFF. When burning, the indicator is displayed. -
Page 9: Features Of The Auto-Recirculation Mode
Features of the Initial Operation Auto-Recirculation Before the first use, do the following: Mode 1. Open the water supply valve. Hot water recirculation system: The Water Heater CLOSED OPEN circulates and warms up the hot water in the pipe. When recirculation is operating, you can get hot water more instantly with less waste of water. -
Page 10: Using The Water Heater
Using the Water Setting Hot Water Heater Temperature Operation Operation 1. The button is ON. 1. The button is ON. PRIORITY indicator is displayed. PRIORITY indicator is displayed. (e.g. 110°F) (e.g. 110°F) • The POWER indicator is displayed. • The POWER indicator is displayed. •... -
Page 11: Customizable Settings
Customizable Settings Limiting the Maximum Output Temperature Temperature Setting Options The maximum output temperature can be limited to prevent discharging hot water at too high of a The temperature settings below are examples. temperature. The temperature setting necessary depends on the usage, the length of piping and the season. -
Page 12: Muting The Remote Controller
Muting the Remote Controller Flow Meter Alarm Stopping Recirculation Operation The Remote Controller will The flow meter alarm is being emit a sound when any button used to indicate when a tub is full. is pressed. This sound can be Operation muted if it is desired. -
Page 13: Preventing Damage From Freezing
Preventing Damage from Freezing • When linking multiple Water Heaters, NOTICE discharge water equivalent to (0.1 gallon (400 mL)/minute per Water Heater.) • Damage can occur from frozen water within 4. The flow may become unstable from time to the appliance and pipes even in warm time. - Page 14 Drain Using the Remote Controller Manual Draining 1. Close the gas valve. 1. The button is OFF. 2. Press and hold the button until a sound is heard (approximately 2 seconds). 2. The button is ON. • The maximum hot water (e.g.
-
Page 15: Regular Maintenance
Regular Maintenance Turning the Water Heater Back On Periodic Inspection DANGER After the Water Heater has been out of use for a Periodic check and maintenance should be long time, make sure that you fill the condensate performed once a year by a qualified service trap with water. - Page 16 Water Drain Valve (with Water Filter) Check : C • For abnormal sounds during operation. • For abnormalities in external appearance, If the water drain valve (with water filter) is covered discoloration or flaws. with debris, the hot water may not run smoothly, or the Water Heater may put out cold water.
-
Page 17: Troubleshooting
Troubleshooting Water Quality and Maintenance Initial Operation • For people who live in a hard water area, periodic flushing is necessary. If the Heat Exchanger is not The Water Heater does not attempt to ignite flushed, the Scale Build-up may cause damage to when water is running. - Page 18 The hot water is not the correct temperature. The amount of hot water at a certain fixture is not constant. • Is the hot water fixture/faucet sufficiently open? • When hot water is demanded at other fixtures, Water takes time to become hot when turning the amount available may be reduced.
- Page 19 Check for an Error Code on the Remote Sounds Controller The fan can be heard after operation is stopped. A motor can be heard when turning the Water Heater on or off, when opening or closing a When a failure occurs, information relating to the fixture, or after the Water Heater has been error blinks on the display.
-
Page 20: Follow-Up Service
Follow-up Service Error Code : 99 Cause : Abnormal combustion Action : Contact the nearest manufacturer’s Requesting Service authorized agent. Error Code : C1# (# = 1-9) First follow the instructions in the troubleshooting Cause : Service Reminder (Notice for periodic section. - Page 21 1. Before the gas conversion is performed, verify Gas Conversion the proper gas conversion kit with your Water Heater model on the table provided below. • If you move to a region that uses a different type Conversion Kit Name Stock Code Conversion Type of gas or if the local gas supply is converted, CONVERSION KIT Propane to...
-
Page 22: Specifications
Specifications • Specifications may be changed without prior notice. • The capacity may differ slightly, depending on the water pressure, water supply, piping conditions, and water temperature. Item Specification Model Name PR199DV (GQ-C3260WXQ-FF US) Installation Indoor / Outdoor Wall mounted Type Air Supply / Exhaust Power Vented... -
Page 23: Warranty
Heat, and any other materials necessary to perform the of PB Heat. If any Product or Product parts supplied by PB exchange, except as stated above. Replacement material Heat are found to have manufacturing defects in materials will be invoiced to the distributor in the usual manner or workmanship, such will be, at PB Heat’s option, repaired... - Page 24 PB Heat distributor who supplied the Product. installation of heating equipment. If this does not result in prompt service, contact PB Heat, 8. Before warranty claims will be honored, PB Heat shall LLC at the address below with details in support of the have the opportunity to directly, or through its authorized warranty claim.
