Amana ACS3350AB Technical Information

Amana Technical InformationSlide-In Gas Range
ACS3350AB PACS3350AB0
ACS3350AS PACS3350AS0
• Due to possibility of personal injury or property damage, always contact an authorized technician for servicing or
repair of this unit.
• Refer to Service Manual RS2310002 for detailed installation, operating, testing, troubleshooting, and disassembly
instructions.
• Refer to Parts Manual RP2310067 for part number information.
All safety information must be followed as provided in Service Manual RS2310002.
To avoid risk of electrical shock, personal injury or death; disconnect power to oven before servicing, unless
testing requires power.
Model
Power Source
Voltage rating
Amperage rating
Frequency
Water Column Pressure
Natural
LP/Propane
Surface Burner (BTU Nat. / LP)
Small
Medium
Large
Oven Burner (BTU Nat. / LP)
Bake
Broil
Convection Element 120 VAC
Oven Interior Dimensions in. (cm)
Height
Width
Depth
November 2001
ACS3350AC
ACS3350AW
!
CAUTION
!
WARNING
ACS3350A* Model
Features
120 VAC One piece cast iron burner grates
15 Amp Frameless glass door with window
60 Hz Interior oven light
Two oven racks − 5 positions
6 in. W.C.P. Removable full width storage drawer
10 in. W.C.P. Self-cleaning porcelain oven
Electronic Range Control
5,000 / 4,000 High performance burners
9,100 / 8,000
Product Exterior Dimensions in. (cm)
12,500 / 10,000 Height overall
Width
15,500 / 15,500 Depth oven door closed with handle
14,000 / 13,000 Clearance oven door
Height of cooktop
16 (41)
Weight lbs. (kg)
23 (58) Approximately shipping weight
17 1/2 (44)
1
PACS3350AC0
PACS3350AW0
ACS3350A*
36 (119)
30 1/8 (76)
23 (72)
20 (51)
36 (91)
171 (78)
RT2310015 Rev. 0
X
X
X
X
X
X
X
X
