Adapter plate WS1 Color
for the conversion of WS20 to WS1 Color
Technical specifications and installation
instructions
Part numbers 60147 (white), 601471 (aluminium coloured)
Elsner Elektronik GmbH Control and Automation Technology
Sohlengrund 16
D - 75395 Ostelsheim
Germany
Phone+49 (0) 70 33 / 30 945-0 info@elsner-elektronik.de
Fax +49 (0) 70 33 / 30 945-20 www.elsner-elektronik.de
echnical Service: +49 (0) 70 33 / 30 945-250
T
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for elsner elektronik 60147
Summary of Contents for elsner elektronik 60147
- Page 1 Adapter plate WS1 Color for the conversion of WS20 to WS1 Color Technical specifications and installation instructions Part numbers 60147 (white), 601471 (aluminium coloured) Elsner Elektronik GmbH Control and Automation Technology Sohlengrund 16 D - 75395 Ostelsheim Phone+49 (0) 70 33 / 30 945-0 info@elsner-elektronik.de Germany Fax +49 (0) 70 33 / 30 945-20 www.elsner-elektronik.de...
- Page 2 • 2 screws with locknuts M4–0,7x10 mm, Allen screw (DIN 7991) 1.2. Technical specifications Colours • white glossy (No. 60147) • aluminium coloured glossy (No. 601471) Dimensions approx. 176 × 176 × 2,5 (W × H × D, mm) The product is compliant with the provisions of EU guidelines.
- Page 3 Installation and commissioning Elsner Elektronik is not liable for any changes in norms and standards which may occur after publication of these operating instructions. 2.2. Preparation for mounting Follow the instructions in the chapter of the same name in the manual for the WS1 Color.
- Page 4 Installation and commissioning Screw the adapter plate with the WS1 Color onto the WS20 concealed box. Remove the protective foil on the dis- play (red tab). Place the WS1 Color frame on the low- er part of the housing. To this end, the frame is first suspended below and then clapped shut above and snapped in place.
