Cleaning
*** All chrome surfaces should be cleaned using a clean damp cloth.
*** No abrasive cleaning agents or materials should be used.
*** General glass cleaner can be used for the screen, but ensure that this
will not damage the chrome, check the cleaning information on the
product before use
This instruction will cover installation of the following units
Codes:
11050
11063
Product Specification
Height: 2000mm
Glass thickness: 10mm
Adjustment:
11050:
11051:
11052:
11053:
11054: 1170-1195mm
11051
11064
730-755mm
770-795mm
870-895mm
970-995mm
1000mm
1200mm
Telephone
0844 484 7678
11052
11053
11065
11066
760mm
800mm
900mm
11054
11055
11067
Advertisement
Related Manuals for Better Bathrooms Trinity Premium
Summary of Contents for Better Bathrooms Trinity Premium
- Page 1 Cleaning *** All chrome surfaces should be cleaned using a clean damp cloth. *** No abrasive cleaning agents or materials should be used. *** General glass cleaner can be used for the screen, but ensure that this will not damage the chrome, check the cleaning information on the product before use This instruction will cover installation of the following units Codes:...
- Page 2 Trinity Premium Wet Room Instruction Images are for installation purposes only Please retain this manual after installation for future reference and maintenance Product must be installed in compliance with relevant Water Bylaws Importance *** Handle with care, impact can damage both the glass and frame...
-
Page 3: Parts List
TOOLS (NOT SUPPLIED) Rubber mallet Allen Key (supplied) Tape Cross Srewdriver Spirit level Silicone gun Drill 3mm Drill Bit Pencil Parts List... -
Page 4: Parts Drawing
Parts Drawing Note: Please ensure your refer to the correct option for your assembly to ensure correct positioning the bracing bars. Option A: Wet Room Option B: Wet Room with Return Panel Figure 1 Figure 2 Option C:Walk-in type... - Page 5 Figure 3 Installation Guide Note: Supporting bar is supplied with 100cm, it needs to be cut to required size Option A: Wet room Step 1 1.1 Place the wall profile(10) to required position, ensure the profile is vertical and marked with pencil on the wall 1.2 Drill holes using 6mm bit 1.3 Tap in the plugs(1)
- Page 6 Step 3 *** Measure the distance from the front glass to the wall and cut supporting bar(4) to the correct length if necessary *** Mark the right position with a pencil 3.2 Drill a hole using a drill bit. 3.3 Using a rubber mallet to insert the wall plugs(1) into the hole Step 4 *** Place the wall fixing plate(2-2) against the...
- Page 7 Option B: Wet Room with Return Panel Step 1 Refer to step 1 of option A: Wet room Step 2 Refer to step 2 of option A: Wet room Step 3 3.1 Push one side of the coner profile(14) to the front glass(6).
- Page 8 Step 5 ***Place the wall fixing plate(2-2) against the hole and secure it with screw(3) ***Put the wall fixing connector(2-1) on the (2-2) ***Put one side of bracing bar(4) into the hole of (2-1) ***Put the other side of bracing bar (4) through the hole of the T shape glass fixture(11) ***Push the other side of T shape glass fixture(11) on the return glass panel glass(12)
- Page 9 Option C:Walk-in type Step 1 1.1Place the wall profile(10) to required position, ensure the profile is vertical and marked with pencil on both sides of the wall 1.2 Refer to step 1.2 of option A: Wet room 1.3 Refer to step 1.3 of option A: Wet room 1.4 Refer to step 1.4 of option A: Wet room Step2 Refer to step 2 of option A: Wet room...
- Page 10 Step3 Refer to step 3 of option B: Wet Room with Return Panel Step4 Refer to step 4 of option B: Wet Room with Return Panel...
- Page 11 Step5 Refer to step 5.1 of option B *** Slide in the connector glass clip (15) into the bracing bar, move the (15) to required position, and fit it on the return panel then place one end of the other bracing bar into the connector glass clip *** Fit supporting bar clip(05) on both front panels *** Tighten all the supporting bar glass clips or connector clips using screws from the top...
