Summary of Contents for TRACEEZ iPet MSP340
- Page 1 MSP340 iPet GPS Tracker http://www.traceez.com...
- Page 2 1. Features: Support 2G Support GPS / GLONASS Cellular service for iPet is required No distance limitation and real-time tracking under GPS and cellular signal coverage, iPet Deco helps you find your pet easily Free APP—iPet (Support Android and IOS) makes you manage iPet simply. With user friendly interface, you can easily know where you pet is, what favorite places it likes to stay and the most important of all, how to find it when it is lost.
- Page 3 2. APP “iPet”: Operating System Version Smart Phone Model MAP System Android 4.3 and above Google Map 7.1 and above iPhone 5S to the latest Apple Map Android...
- Page 4 3. Wearing Positions:...
-
Page 5: Product And Accessories
4. Product and Accessories: ◎ iPet GPS Tracker ◎ USB Charging Cable ◎ Screw driver... -
Page 6: Specifications
5. Specifications: GNSS Module Parameter Description Specification Comment Chipset ublox MAX_8C Receiver type 72-channel u-blox M8 engine, GPS L1C/A, SBAS L1C/A,QZSS L1C/A, GLONASS L1OF, BeiDou B1 Time-To-First-Fix Cold start 27 s All satellites at -130 dBm Hot start All satellites at -130 dBm Aided starts All satellites at -130 dBm Sensitivity... - Page 7 2G Module Parameter Description Specification Comment Chipset ublox Lino 2G Frequencies 850 / 900/1800/ 1900 Network GPRS/EDGE Class 10 Dual stack IPv4 / IPv6 Embedded TCP/IP UDP/IP stack Embedded HTTP/ FTP SSL (HTTPS/FTPS) Software Jamming Detection European eCall (InBand modem) ERA GLONASS Automatic thermal-shutdown CellLocate...
-
Page 8: Physical Specifications
Physical Specifications Item Description Specification Comment Dimension ( Products) Length 105 mm Width 37 mm Height 30 mm Antenna GNSS Internal Support GPS and GLONASS GSM/GPRS Internal Environmental Specifications Item Description Specification Comment Temperature Operating range -10 °C to 55 °C Storage range -20 °C to 80 °C Humidity... -
Page 9: Power Specifications
Power Specifications Item Description Specification Working Time Battery Li-polymer battery 500mA/3.7V Battery Charging USB charging cable 8 pin Quick mode 80mA 5.5 Hours Normal mode 20mA 20 Hours Power consumption Power saving mode 100 Hours Sleep mode 1.6mA 222 Hours... - Page 10 6. Packing: Content Description Tracker Weight 35 g Per full packing set Weight 250 g Per Carton/pcs 50 PCS Per Carton Size 42 cm x 32 cm x32 cm Per Carton Net Weight 12.5 KG Per Carton Gross Weight 13 KG...
